46
Hardware Installation—Installing the IFC-1010/2020
Primary, Non-Fire Alarm
Current (amperes)*
Primary, Fire Alarm
Current (amperes)
Secondary, Non-Fire
Alarm Current (amperes)
Category
(Cont.)
Qty X [Current
Draw] =
Total Qty X [Current
Draw] =
Total Qty X [Current
Draw] =
Total
[ ] x [ ] = [ ] x [ ] = [ ] x [ ] =
[ ] x [ ] = [ ] x [ ] = [ ] x [ ] =
[ ] x [ ] = [ ] x [ ] = [ ] x [ ] =
Notification
Appliances
(Refer to
manufacturing
Instructions
for device
current draws.)
[ ] x [ ] = [ ] x [ ] = [ ] x [ ] =
XPP-1
[ ] x [0.023] = [ ] x [0.032] = [ ] x [0.025] =
XPM-8
(8 zones)
[ ] x [0.147] = [ ] x [0.169] = [ ] x [0.147] =
XPM-8
(4 zones)
[ ] x [0.086] = [ ] x [0.108] = [ ] x [0.086] =
XPM-8L
(8 zones)
[ ] x [0.085] = [ ] x [0.115] = [ ] x [0.085] =
XPC-8
(8 circuits)
[ ] x [0.033] = [ ] x [0.042] = [ ] x [0.033] =
XPC-8
(4 circuits)
[ ] x [0.017] = [ ] x [0.026] = [ ] x [0.017] =
XPR-8
[ ] x [0.004] = [ ] x [0.013] = [ ] x [0.004] =
Miscellaneous
CCM-1
[ ] x [0.107] = [ ] x [0.107] = [ ] x [0.107] =
RPT-680
[ ] x [0.018] = [ ] x [0.018] = [ ] x [0.018] =
A77-716B
[ ] x [0.020] = [ ] x [0.020] = [ ] x [0.020] =
RA-400Z
(when on)
[ ] x [0.006] = [ ] x [0.006] = [ ] x [0.006] =
NIB-96
[ ] x [0.022] = [ ] x [0.022] = [ ] x [0.022] =
MBT-1
n/a n/a [ ] x [0.017] = n/a n/a
UZC-256
[ ] x [0.035] = [ ] x [0.090] = [ ] x [0.035] =
UDACT
[ ] x [0.100] = [ ] x [0.100] = [ ] x [0.100] =
AMG-1
[ ] x [0.060] = [ ] x [0.060] = [ ] x [0.060] =
AMG-E
[ ] x [0.060] = [ ] x [0.060] = [ ] x [0.060] =
ATG-2
[ ] x [0.060] = [ ] x [0.060] = [ ] x [0.060] =
FFT-7
[ ] x [0.060] = [ ] x [0.120] = [ ] x [0.060] =
FFT-7S
[ ] x [0.060] = [ ] x [0.120] = [ ] x [0.060] =
XP5-M
[ ] x [0.00165]
=
[ ] x [0.0030] = [ ] x [0.00165]
=
Continued on next page . . .
