Hardware Installation—Installing the IFC-1010/2020
47
Primary, Non-Fire Alarm
Current (amperes)*
Primary, Fire Alarm
Current (amperes)
Secondary,
Non-Fire Alarm Current
(amperes)
Category
(Cont.)
Qty X [Current
Draw] =
Total Qty X [Current
Draw] =
Total Qty X [Current
Draw] =
Total
XP5-C Relay
[ ] x [0.00084]
=
[ ] x [0.00084]
=
[ ] x [0.00084]
=
XP5-C NAC
[ ] x [0.00148]
=
[ ] x [0.00148]
=
[ ] x [0.00148]
=
[ ] x [ ] = [ ] x [ ] = [ ] x [ ] =
Other devices
drawing
power from
MPS-24A
Terminals TB3-
3 and TB3-4
[ ] x [ ] = [ ] x [ ] = [ ] x [ ] =
Sum Each
Column for
Totals
Primary, Non Alarm
x [ ] =
x [ ] =
Primary, Alarm
x [ ] =
x [ ] =
Secondary, Alarm
x [ ] =
x [ ] =
* MPS-24A or MPS-24E output current required when operating from primary power.
