Johnson Controls LSWU035 Engineering Guide

FORM 145.05-EG2 (618)
28
JOHNSON CONTROLS
TABLE 14 - LSWU070
AIR FLOW 28,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 803.8 693.4 52.5 51.9 42.7 189.9 798.1 690.4 52.6 52.0 43.6 157.8 788 685.3 52.8 52.1 45.0 188.3
75 67 856.6 542.8 57.7 57.4 43.5 201.0 849.3 539.9 57.8 57.5 44.3 166.8 839 535.8 57.9 57.6 45.7 199.0
75 72 926 389.9 62.9 62.8 44.6 215.7 918.7 387.3 63.0 62.9 45.4 179.0 908.4 383.7 63.1 63.0 46.7 213.6
80 62 831.1 821.8 53.2 51.5 43.3 195.7 825.6 818.4 53.3 51.5 44.1 162.7 816.3 811.5 53.5 51.7 45.5 194.3
80 67 861 690.4 57.8 57.3 43.6 202.0 855.9 688.6 57.8 57.4 44.5 167.9 845.5 684 58.0 57.5 45.8 200.4
80 72 928.4 538.3 63.0 62.7 44.7 216.2 920.4 535.4 63.1 62.8 45.5 179.3 910.2 531.8 63.2 62.9 46.8 214.0
85 62 879.9 879.9 56.2 50.8 44.1 206.1 874 874 56.4 50.8 44.9 171.2 865.1 865.1 56.7 51.0 46.3 204.6
85 67 891.2 828 58.2 56.9 44.2 208.4 884.5 824.6 58.3 57.0 45.1 173.0 874.6 819.5 58.5 57.1 46.4 206.6
85 72 929.9 685.6 63.1 62.7 44.7 216.5 923.7 683.3 63.2 62.7 45.5 179.8 911.1 678.5 63.3 62.9 46.8 214.1
AIR FLOW 28,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 782.4 682.3 52.9 52.2 45.9 156.5 772.3 677.1 53.0 52.3 47.4 186.8 765.7 673.7 53.1 52.4 48.3 155.1
75 67 832.6 533.3 58.0 57.7 46.5 165.2 820.8 528.7 58.1 57.9 48.0 196.9 813.5 525.8 58.2 58.0 48.9 163.4
75 72 900.4 380.9 63.2 63.1 47.6 177.1 887.5 376.3 63.4 63.2 49.0 210.9 881 374.1 63.4 63.3 50.0 175.3
80 62 810.9 807.9 53.7 51.8 46.4 161.5 801.7 800.8 53.9 51.9 47.9 193.0 795.3 795.1 54.1 52.0 48.9 160.3
80 67 838.6 681 58.1 57.6 46.7 166.3 829.1 677.1 58.2 57.7 48.1 198.7 821.9 673.7 58.3 57.8 49.1 164.9
80 72 902.3 528.9 63.3 63.0 47.7 177.5 891.1 524.9 63.4 63.1 49.1 211.7 883.1 522.1 63.5 63.2 50.0 175.6
85 62 859.2 859.2 56.9 51.1 47.2 170.0 850.3 850.3 57.2 51.2 48.6 203.2 844.1 844.1 57.4 51.3 49.6 168.9
85 67 867.8 816 58.5 57.2 47.3 171.5 857.9 810.8 58.7 57.3 48.7 204.8 851.2 807.3 58.8 57.4 49.7 170.1
85 72 904.8 676.1 63.4 62.9 47.7 177.9 892.6 671.6 63.5 63.1 49.1 212.0 883.8 668.3 63.6 63.2 50.2 175.8
HIGH EFFICIENCY - AIR FLOW 23,400 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 822.6 666.5 49.3 49.2 43.0 193.9 815.7 663.1 49.4 49.3 43.9 160.9 806.2 658.5 49.6 49.5 45.3 192.1
75 67 879.6 528.8 54.9 54.8 43.9 205.9 873.3 526.2 55.1 55.0 44.7 171.0 860.7 521.1 55.2 55.1 46.1 203.6
75 72 954.6 395.2 60.5 60.4 45.1 221.7 946.1 392 60.6 60.5 46.0 183.8 933.8 387.6 60.7 60.6 47.3 219.0
80 62 849.1 799.5 48.8 48.8 43.6 199.6 842.7 796.1 49.0 48.9 44.5 165.8 833.5 791.3 49.2 49.1 45.8 198.0
80 67 885.2 662 54.6 54.5 44.0 207.1 878.5 659.2 54.7 54.6 44.8 171.9 867.7 654.8 54.9 54.8 46.2 205.1
80 72 956.5 526.1 60.3 60.2 45.2 222.1 948.1 523 60.4 60.3 46.0 184.2 935.6 518.4 60.6 60.5 47.3 219.4
85 62 891.9 891.9 50.1 48.0 44.4 208.7 885.8 885.8 50.4 48.1 45.2 173.3 876.9 876.9 50.7 48.3 46.5 207.1
85 67 913.4 796.6 54.2 54.1 44.7 213.1 906.1 793.2 54.4 54.3 45.5 176.9 896.9 789.1 54.5 54.4 46.8 211.3
85 72 958.5 658.1 60.0 59.9 45.3 222.6 950.4 655.1 60.1 60.0 46.1 184.6 938.7 650.7 60.3 60.2 47.3 220.0
HIGH EFFICIENCY - AIR FLOW 23,400 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 799.5 655.3 49.7 49.6 46.2 159.5 789.8 650.6 49.9 49.8 47.7 190.5 783 647.2 50.0 49.9 48.6 158.1
75 67 854.3 518.5 55.3 55.2 46.9 169.1 842.9 513.8 55.5 55.4 48.4 201.6 835.3 510.8 55.6 55.5 49.3 167.3
75 72 925.6 384.6 60.8 60.7 48.1 181.6 913.3 380.1 61.0 60.9 49.5 216.4 904.7 376.9 61.1 61.0 50.5 179.5
80 62 827.7 788.6 49.3 49.2 46.8 164.5 816.9 782.9 49.5 49.4 48.2 196.3 810.9 779.7 49.6 49.5 49.2 163.1
80 67 861.6 652.2 55.0 54.9 47.1 170.4 850.3 647.5 55.2 55.1 48.5 203.2 842.9 644.5 55.3 55.2 49.6 168.7
80 72 928.2 515.6 60.6 60.5 48.1 182.1 916.2 511.2 60.8 60.7 49.5 217.0 907.3 507.9 60.9 60.8 50.5 179.9
85 62 870.9 870.9 50.9 48.4 47.5 172.1 860.6 860.6 51.3 48.6 48.9 205.5 854.6 854.6 51.6 48.7 49.9 170.8
85 67 889.8 785.8 54.7 54.6 47.7 175.4 879.1 780.9 54.8 54.7 49.1 209.4 871.8 777.6 55.0 54.9 50.1 173.8
85 72 932.4 648.6 60.3 60.2 48.2 182.8 919.6 643.7 60.5 60.4 49.6 217.8 911.5 640.7 60.6 60.5 50.6 180.7
NOTE: EDB-entering dry bulb temp, EWB-entering wet bulb temp, EWT-entering water temp, LWT-leaving water temp, LDB-leaving dry bulb temp,
LWB-leaving wet bulb temp, TMBH-total capacity, SMBH-sensible capacity
Cooling Performance Data (Cont’d)
