Johnson Controls LSWU035 Engineering Guide

FORM 145.05-EG2 (618)
JOHNSON CONTROLS
29
TABLE 15 - LSWU080
AIR FLOW 32,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 901.4 798.5 52.3 52.1 46.6 212.1 894.4 795.2 52.4 52.2 47.6 176.1 884.5 790.4 52.6 52.3 49.0 210.4
75 67 954.7 619 57.7 57.7 47.6 223.5 947 616.1 57.8 57.8 48.6 185.4 935.5 611.5 57.9 57.9 50.0 221.2
75 72 1032 439.7 63.1 63.1 49.2 239.9 1023 436.7 63.3 63.2 50.1 199.0 1010 432.2 63.3 63.3 51.5 237.2
80 62 940.3 940.3 53.2 51.6 47.4 220.4 933.5 933.5 53.4 51.7 48.4 183.1 924 924 53.6 51.8 49.8 218.8
80 67 970.5 796.4 57.6 57.4 48.0 226.8 963 793 57.6 57.5 48.9 188.3 952 788.1 57.8 57.6 50.3 224.7
80 72 1033 614.2 63.0 63.0 49.3 240.2 1026 611.5 63.1 63.1 50.2 199.4 1013 606.9 63.2 63.2 51.6 237.7
85 62 995.5 995.5 56.5 50.9 48.5 232.2 988 988 56.8 51.0 49.5 192.8 978 978 57.0 51.1 50.9 230.4
85 67 998.4 963.7 57.6 57.1 48.6 232.8 993.3 962 57.7 57.1 49.5 193.7 981.7 955.9 57.9 57.3 51.0 231.1
85 72 1041 790.9 62.9 62.9 49.4 241.8 1032 787.6 62.9 62.9 50.3 200.6 1021 783.6 63.1 63.0 51.8 239.4
AIR FLOW 32,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 877.5 787.1 52.7 52.4 50.1 174.7 866.4 781.9 52.8 52.5 51.6 208.5 859.4 778.6 52.9 52.6 52.7 173.2
75 67 927.8 608.5 58.0 58.0 50.9 183.6 916.1 603.9 58.1 58.1 52.5 219.0 907.4 600.6 58.2 58.2 53.6 181.7
75 72 1002 429.3 63.4 63.4 52.5 196.8 989.3 424.9 63.6 63.5 54.0 234.7 980.8 421.9 63.6 63.6 55.0 194.8
80 62 917.3 917.3 53.8 51.9 50.8 181.8 908 908 54.1 52.0 52.4 217.4 900.4 900.4 54.3 52.1 53.5 180.5
80 67 944.7 785 57.9 57.7 51.3 186.7 932.5 779.6 58.0 57.9 52.9 222.6 924.5 776 58.1 57.9 54.0 184.8
80 72 1005 604.2 63.3 63.3 52.5 197.4 991.2 599.3 63.4 63.4 54.1 235.1 982.8 596.3 63.5 63.5 55.1 195.1
85 62 972.1 972.1 57.2 51.2 51.9 191.5 960.4 960.4 57.6 51.3 53.5 228.6 954.5 954.5 57.7 51.4 54.5 190.1
85 67 974.5 952 58.0 57.3 52.0 192.0 963.4 946.7 58.1 57.5 53.5 229.2 956 942.4 58.2 57.5 54.6 190.4
85 72 1013 780.8 63.1 63.1 52.7 198.9 999.5 775.7 63.3 63.3 54.2 236.9 993.4 773.6 63.3 63.3 55.3 197.0
HIGH EFFICIENCY - AIR FLOW 26,000 CFM
EDB EWB
EWT 80 LWT 90 EWT 80 LWT 92 EWT 85 LWT 95
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 901.4 798.5 47.2 47.1 46.6 212.1 894.4 795.2 47.3 47.2 47.6 176.1 884.5 790.4 47.5 47.4 49.0 210.4
75 67 954.7 619 53.8 53.7 47.6 223.5 947 616.1 53.9 53.8 48.6 185.4 935.5 611.5 54.0 53.9 50.0 221.2
75 72 1032 439.7 60.4 60.3 49.2 239.9 1023 436.7 60.5 60.4 50.1 199.0 1010 432.2 60.7 60.6 51.5 237.2
80 62 940.3 940.3 47.1 47.0 47.4 220.4 933.5 933.5 47.3 47.2 48.4 183.1 924 924 47.7 47.6 49.8 218.8
80 67 970.5 796.4 52.5 52.4 48.0 226.8 963 793 52.6 52.5 48.9 188.3 952 788.1 52.7 52.6 50.3 224.7
80 72 1033 614.2 59.2 59.1 49.3 240.2 1026 611.5 59.3 59.2 50.2 199.4 1013 606.9 59.4 59.3 51.6 237.7
85 62 995.5 995.5 50.0 47.9 48.5 232.2 988 988 50.2 48.1 49.5 192.8 978 978 50.6 48.2 50.9 230.4
85 67 998.4 963.7 51.4 51.3 48.6 232.8 993.3 962 51.5 51.4 49.5 193.7 981.7 955.9 51.7 51.6 51.0 231.1
85 72 1041 790.9 57.8 57.7 49.4 241.8 1032 787.6 57.9 57.8 50.3 200.6 1021 783.6 58.1 58.0 51.8 239.4
HIGH EFFICIENCY - AIR FLOW 26,000 CFM
EDB EWB
EWT 85 LWT 97 EWT 90 LWT 100 EWT 90 LWT 102
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
TMBH SMBH LDB LWB
COMP
KW
WATER
FLOW
GPM
75 62 877.5 787.1 47.6 47.5 50.1 174.7 866.4 781.9 47.8 47.7 51.6 208.5 859.4 778.6 47.9 47.8 52.7 173.2
75 67 927.8 608.5 54.1 54.0 50.9 183.6 916.1 603.9 54.3 54.2 52.5 219.0 907.4 600.6 54.4 54.3 53.6 181.7
75 72 1002 429.3 60.8 60.7 52.5 196.8 989.3 424.9 60.9 60.8 54.0 234.7 980.8 421.9 61.0 60.9 55.0 194.8
80 62 917.3 917.3 47.9 47.8 50.8 181.8 908 908 48.2 48.1 52.4 217.4 900.4 900.4 48.5 48.4 53.5 180.5
80 67 944.7 785 52.8 52.7 51.3 186.7 932.5 779.6 53.0 52.9 52.9 222.6 924.5 776 53.1 53.0 54.0 184.8
80 72 1005 604.2 59.5 59.4 52.5 197.4 991.2 599.3 59.7 59.6 54.1 235.1 982.8 596.3 59.8 59.7 55.1 195.1
85 62 972.1 972.1 50.8 48.3 51.9 191.5 960.4 960.4 51.2 48.5 53.5 228.6 954.5 954.5 51.4 48.6 54.5 190.1
85 67 974.5 952 51.8 51.7 52.0 192.0 963.4 946.7 52.0 51.9 53.5 229.2 956 942.4 52.2 52.1 54.6 190.4
85 72 1013 780.8 58.2 58.1 52.7 198.9 999.5 775.7 58.3 58.2 54.2 236.9 993.4 773.6 58.4 58.3 55.3 197.0
NOTE: EDB-entering dry bulb temp, EWB-entering wet bulb temp, EWT-entering water temp, LWT-leaving water temp, LDB-leaving dry bulb temp,
LWB-leaving wet bulb temp, TMBH-total capacity, SMBH-sensible capacity

Johnson Controls LSWU035 Specifications

General

Brand	Johnson Controls
Model	LSWU035
Category	Chiller
Language	English
