Johnson Controls LSWU035 Engineering Guide

FORM 145.05-EG2 (618)
42
JOHNSON CONTROLS
OVERVIEW OF SPLIT SHIPMENT
LSWU050–060 MODELS
STD DIA 1.00 NOM PVC SOCKET
(TO CONNECT METAL PIPE, PLASTIC
WELD ONE UNIVERSAL PN 478-010
SPIGOT FEMALE ADAPTER)
CONNECTION TUBE STUBS
WILL BE DETACHED & SHIPPED
INSIDE UNIT WITH COUPLINGS
24.19
25.44
26.69
Ø 1.38
99.94
12.86*
TYP
10.64* TYP
LIFTING LUG
1.63 TYP
TO COIL SECTION
ELECTRICAL PENETRATIONS
35.00
TO FAN SECTION
REAR
FAN SECTION
NOTE: FILTER SECTION IS NOT SHOWN AND WILL SHIP SEPARATELY
90.00
RIGHT
LEFT
FRONT VIEW 40.57
COIL SECTION
FRONT VIEW
RIGHT
LEFT
.35
4.45
10.12
DRAIN CONNECTION
3.69
Ø 1.38
Ø .88
2.86
5.92
Dimensional Data (Cont’d)
