Johnson Controls M4-CG Series User Manual

Table 11: Technical Specifications for CG Series Controllers
Input and Output Capabilities M4-CGM09090, M4-CGE09090
7 - Universal Inputs: Defined as 0–10 VDC, 4–20 mA, 0–600k ohms, or Binary Dry Contact
2 - Binary Inputs: Defined as Dry Contact Maintained or Pulse Counter/Accumulator Mode
4 - Configurable Outputs: Defined as 0-10 VDC or 24 VAC Triac BO
2 - Analog Outputs: Defined as 0–10 VDC or 4–20 mA
3 - Binary Outputs: Defined as 24 VAC Triac (external power source only)
M4-CGM04060, M4-CGE04060
3 - Universal Inputs: Defined as 0–10 VDC, 4–20 mA, 0–600k ohms, or Binary Dry Contact
1 - Binary Inputs: Defined as Dry Contact Maintained or Pulse Counter/Accumulator Mode
4 - Configurable Outputs: Defined as 0-10 VDC or 24 VAC Triac BO
2 - Binary Outputs: Defined as 24 VAC Triac (external power source only)
Universal Input (UI) Resolution/ Analog
Output (AO) Accuracy
Input: 24-bit Analog to Digital converter
Output: +/- 200 mV accuracy in 0–10 VDC applications
Terminations Input/Output: Pluggable Screw Terminal Blocks
FC Bus, SA Bus, and Supply Power: 4-Wire and 2-Wire Pluggable Screw Terminal Blocks
FC and SA Bus Modular Ports: RJ-12 6-Pin Modular Jacks
Note: The FC Bus Terminal and FC Bus Port are only available on the CGM models
Mounting Horizontal on single 35 mm DIN rail mount (recommended), or screw mount on flat
surface with three integral mounting clips on controller
Housing Enclosure material: ABS and polycarbonate UL94 5VB; Self-extinguishing
Protection Class: IP20 (IEC529)
Dimensions (Height x Width x Depth) M4-CGM09090, M4-CGE09090: 150 mm x 190 mm x 44.5 mm (5-7/8 in. x 7-1/2 in. x 2-1/8
in.) including terminals and mounting clips.
M4-CGM04060, M4-CGE04060: 150 mm x 152 mm x 44.5 mm (5-7/8 in. x 6 in. x 2-1/8 in.)
including terminals and mounting clips
Note: Mounting space requires an additional 50 mm (2 in.) space on top,
bottom, and front face of controller for easy cover removal, ventilation, and wire
terminations.
Weight M4-CGM04060,M4-CGE04060: 0.29 kg (0.64 lb)
M4-CGM09090,M4-CGE09090: 0.5 kg (1.1 lb)
Compliance United States: UL Listed, File E107041, CCN PAZX, UL 916, Energy Management
Equipment
FCC Compliant to CFR47, Part 15, Subpart B, Class A
Canada: UL Listed, File E107041, CCN PAZX7 CAN/CSA C22.2 No. 205, Signal Equipment
Industry Canada Compliant, ICES-003
Europe: Johnson Controls declares that this product is in compliance with the essential
requirements and other relevant provisions of the EMC Directive and RoHS Directive.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
BACnet International: BACnet Testing Laboratories
™
(BTL) Protocol Revision 18 Listed
and Certified BACnet Advanced Application Controller (B-AAC), based on ANSI/ASHRAE
135-2016
1 The VA rating does not include any power supplied to the peripheral devices connected to Configurable Outputs (COs) or Binary
Outputs (BOs), which can consume up to 12 VA for each CO or BO; for a possible total consumption of an additional 84 VA
(maximum).
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond
these specifications, consult the local Johnson Controls office. Johnson Controls shall not be liable for damages resulting from
misapplication or misuse of its products.
M4-CG Series General Purpose Application Controller Installation Guide 23
