Table 10: CG series controller accessories (order separately)
Product Code Number Description
MS-FIT100-0 The Field Inspection Tool or (FIT) is a portable handheld device with a user
interface that is used to test and troubleshoot the BACnet protocol MS/TP RS-485
communications bus that connects supervisory controllers and equipment
controllers to field point interfaces.
The FIT can be used to check out the wiring of the MS/TP RS-485 bus as well
as verify proper communications of supervisory controllers and equipment
controllers connected to the bus. The FIT can be used on both the FC Bus and SA
Bus.
TL-BRTRP-0 Portable BACnet/IP to MS/TP Router
Technical specifications
Table 11: Technical Specifications for CG Series Controllers
Power Requirement 24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz, power supply Class 2
(North America), Safety Extra-Low Voltage (SELV) (Europe)
Power Consumption
M4-CGM models: 14 VA maximum
1
M4-CGE models: 15 VA maximum
Note: The USB feature is not currently supported.
Power Source +15 VDC power source terminals provide 100 mA total current.
M4-CGM09090, M4-CGE09090:
Two +15VDC power sources terminal located in Universal IN terminals for active (3-wire)
input devices
M4-CGM04060, M4-CGE04060:
One +15VDC power sources terminal located in Universal IN terminals for active (3-wire)
input devices
Ambient Conditions Operating: 0°C to 50°C (32°F to 122°F); 10 to 90% RH noncondensing
Storage: -40°C to 80°C (-40°F to 176°F); 5 to 95% RH noncondensing
Supported Network Engines M4-CGM models: All network engine model types
M4-CGE models: All network engine model types at R9.0 or later.
Communications Protocol M4-CGM models: BACnet MS/TP; N2. Zigbee Wireless also supported (at FC Bus and for
Sensors) with additional hardware.
M4-CGE models: BACnet/IP
Device Addressing for BACnet MS/TP Decimal address set via three rotary switches: valid controller device addresses 4-127
Device Addressing for N2 Decimal address set via three rotary switches: valid controller device addresses 1-254
Controller Number for Ethernet
controllers
Three rotary switches to assign a unique number for each controller on the subnet to
identify it in the CCT controller configuration tool for uploading and downloading
Communications Bus M4-CGM models
BACnet MS/TP (default); N2
3-wire FC Bus between the supervisory controller and equipment controllers
M4-CGE models
BACnet/IP (default)
Two Ethernet ports; 10/100 Mbps; 8-pin RJ-45 connector
All M4-CG models
4-wire SA Bus between equipment controller, network sensors and other sensor/actuator
devices, includes a lead to source 15 VDC supply power (from equipment controller) to
bus devices.
Processor RX64M Renesas
®
32-Bit microcontroller
Memory 16 MB flash memory and 8 MB SDRAM
Real-Time Clock Backup Power Supply Super capacitor maintains power to the onboard real-time clock for a minimum of 72
hours when supply power to the controller is disconnected.
M4-CG Series General Purpose Application Controller Installation Guide22
