VAV Controller—Variable Air Volume (VAV) Controller 69
The following table illustrates the selections made through HVAC PRO for
Windows for this example.
Note: The examples contained in this technical bulletin do not reflect all
of the possible questions and answers. These examples are
provided as a basic overview of wiring locations you might expect
to see.
Table 29: Dual Duct Wiring Example 2
Questions and Configuration Selections
HVAC PRO for Windows Questions Configuration Selections
Control Strategy
Pressure Independent
Discharge Air Low Limit
Yes
Exhaust Box Required
No
Baseboard Heat Type
No
Lighting Integration
Yes
VAV5
DA2
DPT2
DA1
DPT1
Hot Deck
Cold Deck
TE1
C1
R1
TE
2
Figure 35: Dual Duct Wiring Example 2
Mechanical Flow Diagram
