RB SERIES ENGINEERING GUIDE
Electrical Data cont.
5
Speed ECM Motor
Model Rated Voltage
Voltage Min/
Max
Compressor
Blower
Motor
FLA
Total
Unit
FLA
Min
Circ
Amp
Max
Fuse/
HACR
Breaker
MCC RLA LRA
015
208-230/60/1 187/253 9.2 5.9 29.0 4.1 10.0 11.5 15
265/60/1 238/292 7.8 5.0 28.0 3.6 8.6 9.8 10/15
018
208-230/60/1 187/253 10.4 6.7 33.5 4.1 10.8 12.5 15
265/60/1 238/292 8.7 5.6 28.0 3.6 9.2 10.6 10/15
024
208-230/60/1 187/253 21.0 13.5 58.3 4.1 17.6 21.0 30
265/60/1 238/292 14.0 9.0 54.0 3.6 12.6 14.9 20
208-230/60/3 187/253 11.0 7.1 55.4 4.1 11.2 13.0 20
460/60/3 414/506 5.5 3.5 28.0 2.1 5.6 6.5 10/15
030
208-230/60/1 187/253 22.0 14.1 73.0 4.1 18.2 21.7 35
265/60/1 238/292 17.5 11.2 60.0 3.6 14.8 17.6 25
208-230/60/3 187/253 13.9 8.9 58.0 4.1 13.0 15.2 20
460/60/3 414/506 6.5 4.2 28.0 2.1 6.3 7.4 10/15
036
208-230/60/1 187/253 22.0 14.1 77.0 4.1 18.2 21.7 35
265/60/1 238/292 19.0 12.2 72.0 3.6 15.8 18.9 30
208-230/60/3 187/253 14.0 9.0 71.0 4.1 13.1 15.4 20
460/60/3 414/506 8.8 5.6 38.0 2.1 7.7 9.1 10/15
041
208-230/60/1 187/253 28.0 17.9 112.0 4.1 22.0 26.5 40
208-230/60/3 187/253 20.6 13.2 88.0 4.1 17.3 20.6 30
460/60/3 414/506 9.3 6.0 44.0 2.1 8.1 9.6 15
042
208-230/60/1 187/253 28.0 17.9 112.0 7.6 25.5 30.0 45
208-230/60/3 187/253 20.6 13.2 88.0 7.6 20.8 24.1 35
460/60/3 414/506 9.3 6.0 44.0 4.0 10.0 11.5 15
048
208-230/60/1 187/253 34.0 21.8 117.0 7.6 29.4 34.9 55
208-230/60/3 187/253 21.4 13.7 83.1 7.6 21.3 24.7 35
460/60/3 414/506 9.7 6.2 41.0 4.0 10.2 11.8 15
060
208-230/60/1 187/253 41.2 26.4 134.0 7.6 34.0 40.6 60
208-230/60/3 187/253 24.9 16.0 110.0 7.6 23.6 27.6 40
460/60/3 414/506 12.1 7.8 52.0 4.0 11.8 13.8 20
070
208-230/60/1 187/253 44.2 28.3 178.0 7.6 35.9 43.0 70
208-230/60/3 187/253 30.0 19.2 136.0 7.6 26.8 31.6 50
460/60/3 414/506 13.6 8.7 66.1 4.0 12.7 14.9 20
HACR circuit breaker in USA only 8/1/18
