RB SERIES ENGINEERING GUIDE
Variable Speed ECM Motor
Model
Rated
Voltage
Voltage
Min/Max
Compressor
Blower
Motor
FLA
Total
Unit
FLA
Min
Circ
Amp
Max
Fuse/
HACR
Breaker
MCC RLA LRA
006
115/60/1 104/127 9.5 6.1 29.0 1.8 7.9 9.4 15
208-230/60/1 187/253 4.7 3.0 15.0 0.9 3.9 4.7 10/15
009
115/60/1 104/127 12.5 8.0 50.0 1.8 9.8 11.8 20
208-230/60/1 187/253 6.4 4.1 21.0 0.9 5.0 6.1 10/15
012
115/60/1 104/127 14.8 9.5 50.0 1.8 11.25 13.6 20
208-230/60/1 187/253 7.7 4.9 25.0 0.9 5.8 7.1 10/15
015
208-230/60/1 187/253 9.2 5.9 29.0 4.0 9.9 11.4 15
265/60/1 238/292 7.8 5.0 28.0 4.1 9.1 10.3 15
018
208-230/60/1 187/253 10.4 6.7 33.5 4.0 10.7 12.4 15
265/60/1 238/292 8.7 5.6 28.0 4.1 9.7 11.1 15
024
208-230/60/1 187/253 21.0 13.5 58.3 4.0 17.5 20.9 30
265/60/1 238/292 14.0 9.0 54.0 4.1 13.1 15.4 20
208-230/60/3 187/253 11.0 7.1 55.4 4.0 11.1 12.9 15
460/60/3 414/506 5.5 3.5 28.0 4.1 7.6 8.5 10/15
030
208-230/60/1 187/253 22.0 14.1 73.0 4.0 18.1 21.6 35
265/60/1 238/292 17.5 11.2 60.0 4.1 15.3 18.1 25
208-230/60/3 187/253 13.9 8.9 58.0 4.0 12.9 15.1 20
460/60/3 414/506 6.5 4.2 28.0 4.1 8.3 9.4 10/15
036
208-230/60/1 187/253 22.0 14.1 77.0 4.0 18.1 21.6 35
265/60/1 238/292 19.0 12.2 72.0 4.1 16.3 19.4 30
208-230/60/3 187/253 14.0 9.0 71.0 4.0 13.0 15.3 20
460/60/3 414/506 8.8 5.6 38.0 4.1 9.7 11.1 15
041
208-230/60/1 187/253 28.0 17.9 112.0 4.0 21.9 26.4 40
208-230/60/3 187/253 20.6 13.2 88.0 4.0 17.2 20.5 30
460/60/3 414/506 9.3 6.0 44.0 4.1 10.1 11.6 15
042
208-230/60/1 187/253 28.0 17.9 112.0 4.0 21.9 26.4 40
208-230/60/3 187/253 20.6 13.2 88.0 4.0 17.2 20.5 30
460/60/3 414/506 9.3 6.0 44.0 4.1 10.1 11.6 15
048
208-230/60/1 187/253 34.0 21.8 117.0 4.0 25.8 31.3 50
208-230/60/3 187/253 21.4 13.7 83.1 4.0 17.7 21.1 30
460/60/3 414/506 9.7 6.2 41.0 4.1 10.3 11.9 15
060
208-230/60/1 187/253 41.2 26.4 134.0 7.0 33.4 40.0 60
208-230/60/3 187/253 24.9 16.0 110.0 7.0 23.0 27.0 40
460/60/3 414/506 12.1 7.8 52.0 6.9 14.7 16.7 20
070
208-230/60/1 187/253 44.2 28.3 178.0 7.0 35.3 42.4 70
208-230/60/3 187/253 30.0 19.2 136.0 7.0 26.2 31.0 50
460/60/3 414/506 13.6 8.7 66.1 6.9 15.6 17.8 25
HACR circuit breaker in USA only 8/1/18
Caution: When installing a unit with a Variable Speed ECM blower motor in 460/60/3 voltage, a neutral wire is
required to allow proper unit operation.
