Johnson Controls RSH Series User Manual

FORM 145.16-IOM2 (0611)
JOHNSON CONTROLS 15
Unit Size
SUPPLY COMPRESSOR BLOWER MIN. CCT. MAX FUSE /
VOLTAGE QTY RLA LRA HP FLA AMPACITY CCT. BKR. AMP
007
208-230/1/60 1 @ 3.0 14.0 0.10 0.8 4.55 15
009
208-230/1/60 1 @ 3.7 22.0 0.10 0.8 5.43 15
012
208-230/1/60 1 @ 4.7 25.0 0.10 0.8 6.68 15
265/1/60 1 @ 4.2 22.0 0.10 1.1 6.35 15
018
208-230/1/60 1 @ 6.5 43.0 0.17 1.2 9.33 15
265/1/60 1 @ 5.8 46.0 0.17 0.8 8.05 15
024
208-230/1/60 1 @ 7.4 43.0 0.25 1.5 10.75 15
265/1/60 1 @ 6.7 46.0 0.25 1.3 9.68 15
208-230/3/60 1 @ 5.9 63.0 0.25 1.5 8.88 15
030
208-230/1/60 1 @ 9.9 54.0 0.33 2.6 14.98 20
265/1/60 1 @ 8.5 46.0 0.33 1.9 12.53 20
208-230/3/60 1 @ 6.9 63.0 0.33 2.6 11.23 15
460/3/60 1 @ 3.6 30.0 0.33 1.2 5.70 15
036
208-230/1/60 1 @ 13.0 74.0 0.50 3.2 19.45 30
265/1/60 1 @ 10.6 66.0 0.50 2.2 15.45 25
208-230/3/60 1 @ 7.8 68.0 0.50 3.2 12.95 20
460/3/60 1 @ 3.7 34.0 0.50 1.9 6.53 15
042
208-230/1/60 1 @ 19.9 109.0 0.50 3.2 28.08 45
208-230/3/60 1 @ 13.1 83.1 0.50 3.2 19.58 30
460/3/60 1 @ 6.1 41.0 0.50 1.9 9.53 15
575/3/60 1 @ 4.2 33.0 0.50 1.7 6.90 15
048
208-230/1/60 1 @ 21.4 135.0 0.75 4.9 31.65 50
208-230/3/60 1 @ 14.5 98.0 0.75 4.9 23.03 35
460/3/60 1 @ 6.3 55.0 0.75 2.2 10.08 15
575/3/60 1 @ 6.0 41.0 0.75 1.7 9.15 15
060
208-230/1/60 1 @ 26.3 134.0 1.00 5.1 37.98 60
208-230/3/60 1 @ 15.6 110.0 1.00 5.1 24.60 40
460/3/60 1 @ 7.8 52.0 1.00 3.2 12.95 20
575/3/60 1 @ 5.8 38.9 1.00 2.6 9.85 15
070
208-230/3/60 1 @ 19.0 123.0 1.00 5.1 28.85 45
460/3/60 1 @ 9.7 62.0 1.00 3.2 15.33 25
575/3/60 1 @ 7.4 50.0 1.00 2.6 11.85 15
