542933-UIM-D-0513
Johnson Controls Unitary Products 23
Clearing a Log Entry
New Event Entry
Service-Menu Button: Master Control
From the system map, the “menu” button can be pressed. Here the main system menu is displayed
(shown below).
Do not remove the USB device until prompted.
Press the Clear button to delete all of the dis-
played log entries. When the clear button is
pressed, the Touch Screen Communicating Con-
trol will delete the log entries per the sort selec-
tion. For example, if “All” is selected in the sort
screen, all of the log entries that have been
saved on Touch Screen Communicating Control
will be cleared (deleted).
Press the “New” button to create a new log entry.
When the “Edit” button has been pressed the
keyboard will pop up to allow the user to manu-
ally input a log entry. This can be used to keep
track of home service, visits, maintenance, etc.
For example, the user can check to see when the
last A-Coil cleaning had taken place (if entered at
time of cleaning).
To Next Page
