Float Switch Settings (AHV)
This screen allows the user to activate the optional condensate float switch (S1-ACS2) and to deter-
mine how the outdoor equipment will shut down.
2-Stage Variable Speed ECM Furnace Auxiliary Settings
This screen allows the user to activate the optional condensate float switch (S1-ACS2) and/or the
optional dry relay contact which is supplied by the utility company.
Float Switch Settings
This screen allows the user to determine how the outdoor equipment will shut down.
Variable Default
Settings
Float switch installed? No Yes, No
Shut down outdoor equip-
ment when float switch is:
Open
Open,
Closed
Variable Default
Settings
Float switch installed?
Yes Not Available
Shut down outdoor equip-
ment when float switch is:
Open
Open,
Closed
Float Switch Installed?
Yes
Float Switch Settings
11:07AM Thu 21 Jul
Shut down outdoor equipment
when float switch is
Open
Back
Select the appropriate settings on the control you.would like to use.
Auxiliary Settings
11:07AM Thu 7/21
NextBack
Auxiliary Switch
Float Switch
Indoor Equipment
Float Switch Installed?
Yes
Auxiliary Settings
11:07AM Thu 7/21
Shut down outdoor equipment
when float switch is
Open
NextBack
