Hardware Installation S300-DIN-RDR2S Module
32 24-10239-413 Rev. A
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2010 Johnson Controls, Inc.
OUT13 Reader 1
Shunt Output
Output is set every time an access
grant occurs.
SIO 1
General Purpose Output 3
Output is logically mapped to output
po
int 3. It can be timed, set, reset,
fast flash, or slow flash.
Output is an open collector that
switches to ground.
OUT01 N/A SIO 1
General Purpose Output 4
Output is logically mapped to output
point 4. It can be timed, set, reset,
fast flash, or slow flash.
Output is an open collector that
switches to ground.
NC or
NO
Reader 1
Door Strike
Output is set every time an access
grant or auxiliary access occurs.
SIO 1
General Purpose Output 5
Output is logically mapped to output
point 5. It can be timed, set, reset,
fast flash, or slow flash.
OUT21 Reader 2
Red Light Output
Output is set every time an access
de
ny occurs.
SIO 2
General Purpose Output 1
Output is logically mapped to output
point 1. It can be timed, set, reset,
fast flash, or slow flash.
Output is an open collector that
switches to ground.
OUT22 Reader 2
Green Light Output
Output is set every time an access
grant occurs.
SIO 2
General Purpose Output 2
Output is logically mapped to output
po
int 2. It can be timed, set, reset,
fast flash, or slow flash.
Output is an open collector that
switches to ground.
OUT23 Reader 2
Shunt Output
Output is set every time an access
grant or auxiliary access occurs.
SIO 2
General Purpose Output 3
Output is logically mapped to output
point 3. It can be timed, set, reset,
fast flash, or slow flash.
Output is an open collector that
switches to ground.
Table 5: Output Point Signals (CK721-A/CK721/CK720/CK705 Controllers)
Signal
Names
RDR Mode Enabled SIO Mode Enabled
