About this task:
Before you commission the Airwall and can access the SBH300 over the Internet, configure the
Ethernet setting. To configure the SBH300 Ethernet settings complete the following steps:
1. Connect the Ethernet cable from SBH300 to an external router, cellular modem, or building
network LAN port.
2. Log on to the SBH300 local UI with the Wi-fi access point. See Connecting to the SBH with the
Wi-Fi access point.
3. To configure an Ethernet cable connection, click Settings > Ethernet, and enter the necessary
data as outlined in the following table:
Table 3: SBH300 Ethernet settings
Field Setting
Ethernet Default: On
Hostname Default: SBH300 followed by the Ethernet MAC Address.
You can change the Hostname, but it must be unique for each device on a
network.
Domain Name
Suffix
Automatically populated
Ethernet MAC
Address
Automatically populated
Auto DHCP
Configure
Default: On
If you want or need to use the SBH300 with a static IP address, you must
set this field to Off. Obtain the IP Address, Subnet Mask, and Default
Gateway from your IT Department and fill out the fields manually. When
left to On, these fields populate automatically.
IP Address See Auto DHCP Configure above.
Subnet Mask See Auto DHCP Configure above.
Default Gateway See Auto DHCP Configure above.
Auto DNS
Configure
Default: Off
The SBH300 includes Tempered Airwall zero-trust software. To use the
Airwall protection, set Auto DNS to Off.
Primary DNS
Server
Address of your Primary DNS Server, if available
The SBH300 includes Tempered Airwall zero-trust software. To use the
Airwall protection, configure the Primary DNS Server to 9.9.9.9.
Secondary DNS
Server
Address of your Secondary DNS Server, if available
The SBH300 includes Tempered Airwall zero-trust software. To use the
Airwall protection, configure Secondary DNS Server to 149.112.112.112.
4. To save your changes, click Save.
What to do next:
The SBH300 includes industry standard Zero Trust Security. The SBH300 requires certain ports open
on the network to establish secure communications to Johnson Controls cloud services.
If you are using a building network or building owner provided wireless internet source, make sure
that the network allows TCP 8096 and UDP 10500 open outbound only. See .
Configuring the Internet connection Wi-Fi Client
Verasys Smart Building Hub (SBH300) Installation Guide12
