Johnson Controls SBH300 User Manual

Accessories
Table 8: SBH300 accessories
Product code Description
ACC-PWRKIT-1A24 24 VDC, Class II power supply, North American
plug
ACC-PWRKIT-1E24 24 VDC, Class II power supply, European plug
ACC-WFUSB-LM808 USB Wi-Fi Adapter
Repair information
If the SBH300 fails to operate within its specifications, replace the unit. For a replacement SBH300,
contact the nearest Johnson Controls representative.
Do not open the SBH300 housing. The SBH300 has no user-serviceable parts inside.
Technical specifications
Table 9: Technical specifications
Specification Description
LC-SBH300-0, Verasys Smart Building Hub
(SBH300)
Product code numbers
LC-SBH300-0C, Connected Verasys Smart
Building Hub (SBH300) with ICG-150 cellular
modem
Power requirement Dedicated nominal 24 VAC power transformer or
a portable power adapter that supplies 24 VDC.
In North America, use a Class 2, 24 VAC power
supply with a 50 VA minimum output.
Outside North America, use a 24 VAC SELV
transformer at the appropriate rating. The
minimum input voltage for the SBH300 to
operate properly is 20 VAC:
ACC-PWRKIT-1A24; Europe Plug Type: ACC-
PWRKIT-1E24
Power consumption 38 W maximum
Ambient temperature conditions Operating: -30°C to 70°C (-22°F to 158°F)
Operating survival: -30°C to 70°C (-22°F to 158°F)
Non-operating: -40°C to 70°C (-40°F to 158°F)
Ambient humidity conditions Storage: 5% RH to 95% RH, 30°C (86°F)
maximum dew point conditions
Operating: 10% RH to 90% RH, 30°C (86°F)
maximum dew point conditions
Transmission speeds Ethernet communication: 10 Mbps, 100 Mbps,
1Gbps
Transmission power Wi-Fi access point dongle,
maximum
100 mW
Verasys Smart Building Hub (SBH300) Installation Guide22
Johnson Controls
