Johnson Controls SE-ZEC510-1 User Manual

Smart Equipment Controls
Installation, Operation and Maintenance Manual
Form No. SECIOM.A
Effective Date: 07/05/19
Page 12
Home
Page
Setpoints
Discharge Air
Setpoint
Heating Max
●
When the space temperature drops below the
heating setpoint the zone controller will start from
the supply air temperature setpoint and reset to the
supply air setpoint heating max. Once the heating
max setpoint is reached the supply air flow will be
reset from heating minimum flow to cooling
maximum flow.
Adjustable:
45°F to 140°F
Home
Page
Setpoints
Discharge Air
Temperature
Setpoint
●
When the space temperature drops below the
heating setpoint the zone controller will start from
the supply air temperature setpoint and reset to the
supply air setpoint heating max. Once the heating
max setpoint is reached the supply air flow will be
reset from heating minimum flow to cooling
maximum flow.
Adjustable:
45°F to 130°F
Outputs
Heating
Command
●
Displays the heat command (on/off) of the heat
output to the proportional actuator or electric heat
Read Only
Outputs Heating Output
● ●
Displays the heat command (0-100%) of the heat
output to the proportional actuator or electric heat
Read Only
Outputs
Heating Stage 1
Command
●
D
isplays status of stage 1 heat. Read Only
Outputs
Heating Stage 2
Command
●
D
isplays status of stage 2 heat. Read Only
Outputs
Heating Stage 3
Command
●
D
isplays status of stage 3 heat. Read Only
Outputs
S
upplemental
Heating Output
● ●
Displays the supplemental heat command (0-
100%) of the heat output to the proportional
actuator or electric heat
Read Only
Outputs
Supplemental
Heating Stage 1
Command
●
D
isplays status of stage 1 supplemental heat. Read Only
Factory Programmed Parameters
This section outlines how the SE-ZEC Controller parameters are programmed at the factory.
Default Parameters
The following table shows factory programming for SE-ZEC Controller parameters that are independent of inlet size and
control sequence.
Table 5: Factory Programmed Default Parameters
Parameter Name
Value
Supplemental Heating Stroke Time
N/A
Supplemental Heating Polarity
N/A
BACnet ID
10000
BACnet Encoding Type
ISO10646
Power Fail Restart Time
180
Warmer/Cooler Adjust Range
3
Warmup Differential
10
Autocalibration Command
FALSE
Zone Temperature Offset
0
