Johnson Controls SE-ZEC510-1 User Manual

Smart Equipment Controls
Installation, Operation and Maintenance Manual
Form No. SECIOM.A
Effective Date: 07/05/19
Page 13
Supply Air Temperature Offset
0
Discharge Air Temperature Offset
0
Heating Limit Enable
TRUE
Heating Supply Air Limit
75
Rotation
90
Warmup Min Flow
200
Occupied Cooling Setpoint
72
Occupied Heating Setpoint
68
Unoccupied Cooling Setpoint
85
Unoccupied Heating Setpoint
55
Standby Cooling Setpoint
77
Standby Heating Setpoint
66
Standalone Min Occupied Time
15
Actuator Stroke Time
60
Size Dependent Parameters
The following table shows factory programming for SE-ZEC Controller parameters that are inlet size dependent.
Table 6: Factory Programmed Size Dependent Parameters
Size
4
5
6
7
8
9
10
12
14
16
20
22
Supply Area 0.087 0.136 0.196 0.267 0.349 0.442 0.545 0.785 1.069 1.396 0.738 2.667
Supply
Airflow
Pickup Gain
2.329 2.327 2.332 2.325 2.329 2.327 2.327 2.327 2.328 2.328 1.982 2.328
Cooling
Maximum
Flow
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Occupied
Cooling Min
Flow
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Unoccupied
Cooling Min
Flow
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Occupied
Heating Min
Flow
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Unoccupied
Heating Min
Flow
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Per
Order
Staged
Device Min
Flow
55 85 110 140 190 240 300 425 580 750 425 1800
