Johnson Controls SE-ZEC510-1 User Manual

Smart Equipment Controls
Installation, Operation and Maintenance Manual
Form No. SECIOM.A
Effective Date: 07/05/19
Page 15
FAN-TYPE Series Series Series Series Series Series Series
Number of Heating
Stages
No Heat 1 2 3 No Stages No Stages No Heat
Damper Polarity Reverse Reverse Reverse Reverse Reverse Reverse Reverse
Supplemental
Heating Installed
FALSE FALSE FALSE FALSE FALSE FALSE TRUE
Box Heating Installed TRUE TRUE TRUE TRUE TRUE TRUE TRUE
Box Heating Stroke
Time
N/A N/A N/A N/A N/A 60 N/A
Box Heating Polarity N/A N/A N/A N/A N/A Normal N/A
Staged Device Min
Flow
0 0 0 0 0 N/A 0
Occupancy
Determination Flow
Setpoint
0 0 0 0 0 0 0
Occupancy Polarity Close Close Close Close Close Close Close
Occupancy Sensor
Enable
TRUE TRUE TRUE TRUE TRUE TRUE TRUE
Standalone Mode TRUE,FALSE
TRUE,FALSE
TRUE,FALSE
TRUE,FALSE TRUE,FALSE
TRUE,FALSE
TRUE,FALSE
TRUE,FALSE TRUE,FALSE
Control Code 6301, 7301
6302, 7302,
6306, 7306
6303, 7303 6304, 7304
6305, 7305,
6308, 7308
6307, 7307 6309, 7309
Heating Type Cooling Only Staged Staged Staged SCR Incremental Staged
FAN-TYPE Parallel Parallel Parallel Parallel Parallel Parallel Parallel
Number of Heating
Stages
No Heat 1 2 3 No Stages No Stages No Heat
Damper Polarity Reverse Reverse Reverse Reverse Reverse Reverse Reverse
Supplemental
Heating Installed
FALSE FALSE FALSE FALSE FALSE FALSE TRUE
Box Heating Installed TRUE TRUE TRUE TRUE TRUE TRUE TRUE
Box Heating Stroke
Time
N/A N/A N/A N/A N/A 60 N/A
