System 450™ Series Control Module with Ethernet Communications Installation Instructions
52
Technical Specifications
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult Johnson Controls Application Engineering at (414) 524-5535. Johnson Controls shall not be liable for damages resulting
from misapplication or misuse of its products.
C450CEN-1C Control Module with Ethernet Communications
Product C450CEN: System 450 control modules are sensing controls and operating controls with
LCD and four-button touchpad UI, Ethernet communications capability, and no outputs.
C450CEN-1C: Control module with Ethernet communications capability
Supply Power Internal Supply Power: C450YNN-1C Power Supply Module
External Supply Power: 24 VAC (20–30 VAC) Safety Extra-Low Voltage (SELV) (Europe),
Class 2 (North America), 50/60 Hz, 10 VA minimum
Note: A System 450 control module or module assembly can use an internal or an external
supply power source, but must not be connected to both simultaneously.
Ambient Operating
Conditions
Temperature: -40 to 66C (-40 to 150F)
Humidity: Up to 95% RH non-condensing; maximum dew point 29C (85F)
Ambient Shipping and
Storage Conditions
Temperature: -40 to 80C (-40 to 176F)
Humidity: Up to 95% RH non-condensing; maximum dew point 29C (85F)
Input Signal 0–5 VDC; 1,035 ohm at 25C (77F) for an A99 PTC Temperature Sensor
Analog Input Accuracy Resolution: 16 bit
Control Construction Independently mounted control, surface mounted with Lexan® 950 enclosure suitable for
DIN rail mounting or direct mounting to a hard, even surface.
Dimensions (H x W x D) 127 x 63 x 63 mm (5 x 2-3/8 x 2-3/8 in.)
Weight C450CEN-1C: 207 g (0.46 lb)
Compliance United States: cULus Listed; UL 60730-1, File E27734; FCC Compliant to CFR47, Part
15, Subpart B, Class B
Canada: cULus Listed; CAN/CSA-E60730-1, File E27734; Industry Canada (IC) Compliant
to Canadian ICES-003, Class B limits
Europe: CE Mark – Johnson Controls declares that this product is in compliance with the
essential requirements and other relevant provisions of the EMC Directive.
Australia and New Zealand: RCM Mark, Australia/NZ Emissions Compliant
