System 450™ Series Control Module with Ethernet Communications Installation Instructions
37
Sensor Configuration Page
Figure 10 shows an example Sensor Configuration page for a System 450 control system that is already
configured and in operation. On the Sensor Configuration page, you set up the hard-wire sensors (Sn-1, Sn-2, and
Sn-3) and the Differential Sensor (Sn-d), if your control system uses the Differential Control feature.
This example uses a pressure sensor (Sn-1), a temperature sensor (Sn-2), and a humidity sensor (Sn-3). This
control system example does not use the Differential Control feature.
Table 16 provides descriptions, user actions, and references for the items called out in Figure 10.
6Relay Output
Setup Access
Buttons
Click the button (showing a small wrench head) to the left of a Relay Output (OUTR-x)
status row to go to that relay output’s configuration page.
Note: The control module automatically detects the type and position of the control
system outputs in the module assembly and assigns an output type and unique output
number for each output in your system.
See Relay Output Configuration Page
on page 44 for more information on setting up relay
outputs in the web UI.
In this example, Outputs 3 and 4 are relay outputs.
7 Logout
Button
Click Logout to log out of the System Configuration page and go to the System Overview
page.
Note: After 15 minutes of inactivity in the System Configuration page, the System 450 UI
automatically logs out of the web UI.
Table 15: System 450 Web UI System Configuration Page User Actions, Descriptions, and References (Part
2 of 2)
Callout
Number
Identifier / Item
Name
User Actions, Descriptions, References
