TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin16
Dehumidification Hysteresis
(TEC2636-4, TEC2636H-4,
TEC2636H-4+PIR, TEC2656-4,
TEC2656H-4, and
TEC2656H-4+PIR Models)
AV 72 2 to 20% RH
Dehumidification MaxCool
(TEC2636-4, TEC2636H-4,
TEC2636H-4+PIR, TEC2656-4,
TEC2656H-4, and
TEC2656H-4+PIR Models)
AV 73 20 to 100% RH
Control Type
3
(TEC2626-4, TEC2626H-4,
TEC2626H-4+PIR, TEC2636-4,
TEC2636H-4, and
TEC2636H-4+PIR Models)
BV 75 0 = On/Off
1 = Floating
Floating Motor Timing
3
(TEC2626-4, TEC2626H-4,
TEC2626H-4+PIR, TEC2636-4,
TEC2636H-4, and
TEC2636H-4+PIR Models)
MSV 76 1 = 0.5 Minutes
2 = 1.0 Minute
3 = 1.5 Minutes
4 = 2.0 Minutes
5 = 2.5 Minutes
6 = 3.0 Minutes
7 = 3.5 Minutes
8 = 4.0 Minutes
9 = 4.5 Minutes
10 = 5.0 Minutes
11 = 5.5 Minutes
12 = 6.0 Minutes
13 = 6.5 Minutes
14 = 7.0 Minutes
15 = 7.5 Minutes
16 = 8.0 Minutes
17 = 8.5 Minutes
18 = 9.0 Minutes
On/Off Control CPH
3
(TEC2616-4, TEC2616H-4,
TEC2616H-4+PIR, TEC2626-4,
TEC2626H-4, TEC2626H-4+PIR,
TEC2636-4, TEC2636H-4, and
TEC2636H-4+PIR)
MSV 77 1 = 3 CPH
2=4CPH
3=5CPH
4=6CPH
5=7CPH
6=8CPH
Table 3: TEC26x6(H)-4 and TEC26x6H-4+PIR Series MS/TP Bus Objects
(Part 6 of 7)
Point Name Thermostat Point
(Type/Address)
Range
