TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin 19
Filter Alarm
5
BI 36 0 = Off
1=On
Service Alarm
5
BI 37 0 = Off
1=On
Occupied Heat Setpoint
3, 7
AV 39 40.0°F/4.5°C to
90.0°F/32.0°C
Occupied Cool Setpoint
3, 7
AV 40 54.0°F/12.0°C to
100.0°F/37.5°C
Stand-by Heat Setpoint
3, 7
AV 41 40.0°F/4.5°C to
90.0°F/32.0°C
Stand-by Cool Setpoint
3, 7
AV 42 54.0°F/12.0°C to
100.0°F/37.5°C
Unoccupied Heat Setpoint
3, 7
AV 43 40.0°F/4.5°C to
90.0°F/32.0°C
Unoccupied Cool Setpoint
3, 7
AV 44 54.0°F/12.0°C to
100.0°F/37.5°C
BI1 Configuration
3
MSV 46 1 = None
2=RemNSB
3=MotionNO
4=MotionNC
5 = Window
BI2 Configuration
3
MSV 47 1 = None
2 = Door Dry
3 = Override
4=Filter
5=Service
UI3 Configuration
3
MSV 48 1 = None
2 = COC/NH
3 = COC/NC
4=COS
5=SS
Menu Scroll
3
BV 49 0 = No Scroll
1 = Scroll Active
Auto Mode Enable
3
BV 50 0 = Disabled
1 = Enabled
Temperature Scale
3
BV 51 0 = °C
1=°F
AUX (BO5) Configuration
3
MSV 54 1 = Not Used
2 = NO with Occ
3 = NC with Occ
4=NOwithOccandFan
5 = NC with Occ and Fan
6 = Network Controlled
Password Value AV 56 0 to 1,000
Heating Setpoint Limit
3
AV 58 40.0°F/4.5°C to
90.0°F/32.0°C
Cooling Setpoint Limit
3
AV 59 54.0°F/12.0°C to
100.0°F/37.5°C
Setpoint Type
3
BV 60 0 = Permanent
1 = Temporary
Setpoint Function BV 61 0 = Dual Setpoints
1 = Attached Setpoints
Table 4: TEC2645-4 MS/TP Bus Objects (Part 2 of 4)
