Johnson Controls TEC2645-4 User Manual

TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin 23
BI2 Status
5, 6
BI 30 0 = Deactivated
1 = Activated
UI3 Status
5, 6
BI 31 0 = Deactivated
1 = Activated
Local Motion
5
BI 32 0 = Deactivated
1 = Activated
Effective Occupancy
5
MSV 33 1 = Occupied
2 = Unoccupied
3 = Temporary Occupied
4 = Stand-by
Window Alarm
5
BI 35 0 = Off
1=On
Filter Alarm
5
BI 36 0 = Off
1=On
Service Alarm
5
BI 37 0 = Off
1=On
Occupied Heat Setpoint
3, 7
AV 39 40.0°F/4.5°C to
90.0°F/32.0°C
Occupied Cool Setpoint
3, 7
AV 40 54.0°F/12.0°C to
100.0°F/37.5°C
Stand-by Heat Setpoint
3, 7
AV 41 40.0°F/4.5°C to
90.0°F/32.0°C
Stand-by Cool Setpoint
3, 7
AV 42 54.0°F/12.0°C to
100.0°F/37.5°C
Unoccupied Heat Setpoint
3, 7
AV 43 40.0°F/4.5°C to
90.0°F/32.0°C
Unoccupied Cool Setpoint
3, 7
AV 44 54.0°F/12.0°C to
100.0°F/37.5°C
BI1 Configuration
3
MSV 46 1 = None
2=RemNSB
3=MotionNO
4=MotionNC
5 = Window
BI2 Configuration
3
MSV 47 1 = None
2 = Door Dry
3 = Override
4=Filter
5=Service
UI3 Configuration
3
MSV 48 1 = None
2 = COC/NH
3 = COC/NC
4=COS
5=SS
Menu Scroll
3
BV 49 0 = No Scroll
1 = Scroll Active
Temperature Scale
3
BV 51 0 = °C
1=°F
Out 1 (BO1 and BO2)
Configuration
3
MSV 53 1 = False
2=True
Table 5: TEC26x7-4 and TEC26x7-4+PIR Series MS/TP Bus Objects (Part 2 of 4)
Point Name Thermostat Point
(Type/Address)
Range
