TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin24
AUX (BO5) Configuration
3
MSV 54 1 = Not Used
2 = NO with Occ
3 = NC with Occ
6 = Network Controlled
Password Value AV 56 0 to 1,000
Heating Setpoint Limit
3
AV 58 40.0°F/4.5°C to
90.0°F/32.0°C
Cooling Setpoint Limit
3
AV 59 54.0°F/12.0°C to
100.0°F/37.5°C
Setpoint Type
3
BV 60 0 = Permanent
1 = Temporary
Temporary Occupancy Time
3
MSV 62 1 = 0 Hours
2=1Hour
3=2Hours
4=3Hours
5=4Hours
6=5Hours
7=6Hours
8=7Hours
9=8Hours
10 = 9 Hours
11 = 10 Hours
12 = 11 Hours
13 = 12 Hours
14 = 13 Hours
15 = 14 Hours
16 = 15 Hours
17 = 16 Hours
18 = 17 Hours
19 = 18 Hours
20 = 19 Hours
21 = 20 Hours
22 = 21 Hours
23 = 22 Hours
24 = 23 Hours
25 = 24 Hours
Deadband
3
AV 63 2F°/1C° to
5F°/2.5C°
Reheat Time Base (BO5)
3
BV 64 0 = 15 Minutes
1 = 10 Seconds
Proportional Band MSV 65 1 = 3 (3°F/1.7°C)
2 = 4 (4°F/2.2°C)
3 = 5 (5°F/2.8°C)
4 = 6 (6°F/3.3°C)
5 = 7 (7°F/3.9°C)
6 = 8 (8°F/4.4°C)
7 = 9 (9°F/5.0°C)
8 = 10 (10°F/5.6°C)
Stand-by Time
3
AV 67 0.5 Hours to
24.0 Hours
Unoccupied Time
3
AV 68 0.0 Hours to
24.0 Hours
Control Type (TEC2627-4
Model)
3
BV 75 0 = On/Off
1 = Floating
Table 5: TEC26x7-4 and TEC26x7-4+PIR Series MS/TP Bus Objects (Part 3 of 4)
Point Name Thermostat Point
(Type/Address)
Range
