TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin 45
Fan Mode MSV 17 Available state text and default value
depends on Fan Mode Sequence (MV58)
value upon device discovery.
MSV17 Index function - MSV58 Text
Index:
1 = 1 Low - 2 Medium - 3 High
2 = 1 Low - 2 High
3 = 1 Low - 2 Medium - 3 High - 4 Auto
4 = 1 Low - 2 High - 3 Auto
5 = 1 Auto - 2 On
Occupancy Command MSV 18 1 = Local Occupancy
2 = Occupied
3 = Unoccupied
Keypad Lockout MSV 19 1 = Level 0
2 = Level 1
3 = Level 2
4 = Level 3
5 = Level 4
6 = Level 5
PI Heating Demand AV 21 0 to 100%
PI Cooling Demand AV 22 0 to 100%
Dehumidification Status BI 23 0 = Off
1 = On
Fan Status MSV 28 1 = Off
2 = Low
3 = Medium
4 = High
BI 1 Status BI 29 0 = Deactivated
1 = Activated
B1 2 Status BI 30 0 = Deactivated
1 = Activated
Local Motion BI 32
Effective Occupancy MSV 33 1 = Occupied
2 = Unoccupied
3 = Temporary Occupied
4 = Stand-by
Window Alarm BI 35 0 = Off
1 = On
Filter Alarm BI 36 0 = Off
1 = On
Service Alarm BI 37 0 = Off
1 = On
Occupied Heat Setpoint AV 39 40.0°F/4.5°C to
90.0°F/32.0°C
Occupied Cool Setpoint AV 40 54.0°F/12.0°C to
100.0°F/37.5°C
Stand-by Heat Setpoint AV 41 40.0°F/4.5°C to
90.0°F/32.0°C
Stand-by Cool Setpoint AV 42 54.0°F/12.0°C to
100.0°F/37.5°C
Unoccupied Heat Setpoint AV 43 40.0°F/4.5°C to
90.0°F/32.0°C
Table 11: TEC26xx-0+PIR (Part 2 of 5)
Point Name Thermostat Point
(Type/Address)
Range
To Next Page
