TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin 48
Metasys® and Johnson Controls® are registered trademarks of Johnson Controls, Inc.
All other marks herein are the marks of their respective owners. © 2013 Johnson Controls, Inc.
Building Efficiency
507 E. Michigan Street, Milwaukee, WI 53202
Heat CPH MSV 84 3 = 3 CPH
4 = 4 CPH
5 = 5 CPH
6 = 6 CPH
7 = 7 CPH
8 = 8 CPH
Cool CPH MSV 85 3 = 3 CPH
4 = 4 CPH
5 = 5 CPH
6 = 6 CPH
7 = 7 CPH
8 = 8 CPH
Heat NO NC BV 86 0 = Normally Open
1 = Normally Closed
Cool No NC BV 87 0 = Normally Open
1 = Normally Closed
Heat Demand Limit AV 88 0 to 100%
Cool Demand Limit AV 89 0 to 100%
Pulsed Heat MSV 90 0 = Off
1 = On
2 = Occupancy Output
RUI 1 Status BI 91 0 = Deactivated
1 = Activated
RBI 2 Status BI 92 0 = Deactivated
1 = Activated
Cooling Valve Status BI 93 0 = Off
1 = On
Heating Valve Status BI 94 0 = Off
1 = On
Fan Control MSV 95 0 = On
1 = Off - Auto
2 = Off - All
Table 11: TEC26xx-0+PIR (Part 5 of 5)
