Johnson Controls YEWS Series User Manual

AI16 CURRENT
DO1
DO2 MOTOR Y CONTACT
DO3 MOTOR △ CONTACT
DO4
DO5
DO6
PUMP
OIL HEATER
BYPASS VALVE1
ALARM
RETU
NEXT
BACK
ON
ON
ON
ON
ON
ON
18.0Amp
01#
This interface displays the input status of DO relay of the
main board.
ON indicate the digital output is closed.
(4)Status Display Interface-4
Press F1 to return to the main interface.
Press F3 to return to the previous display interface.
Press F4 to enter into the next display interface.
DO7 VALVE LIQ.INJ.D
DO8 BYPASS UAL UE2
DO9 RUN STATUS
DO15 CR4
DO16 CR3
ON
ON
ON
ON
ON
RETU
NEXT
BACK
01#
This interface displays the output status of DO relay of
the main board.
ON indicate the digital output is closed.
(5)Status Display Interface-5
Press F1 to return to the main interface.
Press F3 to return to the previous display interface.
Press F4 to enter into the next display interface.
FLOW SW
DIS.P SW
OIL SW.
DI1
DI2 RUN MODE SW
DI3
DI4
DI5 MOTOR PROTECTION
DI6 EXT.INTERLOCK
DI7 START FAULT
DI8 REMOTE
ON
OFF
ON
ON
ON
ON
ON
ON
RETU
BACK
NEXT
01#
POWER SUPPLY 3P-415V-50Hz
COMP MODEL YFS205LBF
MAX. LOAD AMP 18.0 Amp
HMI VER. RMSYEWSD100/V1.01
RETU
BACK
RMSYEWSD100/V1.01
0HOUR
0HOUR
0
I/O VER.
RUN TIME
COMP ON-OFF CNT
COMP RUN TIME
01#
POWER SUPPLY：Power supply of unit.
COMP MODEL：Model of compressor in this unit.
MAX.LOAD AMP：Maximal load amp of motor.
HMI VER. ：Firmware version of XS08.
I/O VER. ：Firmware version of YORK003.
RUN TIME：Accumulated running time of the pump
COMP RUN TIME：Accumulated running time of the
compressor
COMP ON-OFF CNT： Startup times of the com-
pressor
Note: In top right corner, the digital box can be entered
with setting values. This setting is for switching display
information of different system. Enter 01 for displaying
information of system1 and 02 for displaying infor-
mation of system2, and the same case for others. System
2 is only used in the system with dual compressor(YE-
WS250).
5.4.4 Parameter setting
In the main interface, press F2 to enter into the parameter
setting interface, the operation instructions for the keys
are as follows:
This interface displays the input status of DI switch of
the main board.
ON indicate the digital output is closed.
(6)Status Display Interface-6
Press F1 to return to the main interface.
Press F3 to return to the previous display interface.
YEWS-E Water Cooling Screw Chiller/Heat Pump
27
