YORK INTERNATIONAL
2
FORM 150.62-NM6 (LS1)
ELECTRICAL DATA – DUAL POINT POWER SUPPLY CONNECTIONS – YCAL0040E_ - YCAL0080E_
TABLE 3 – DUAL POINT POWER SUPPLY CONNECTIONS
(Two Field Provided Power Supply Circuits to the chiller. Field connections to Factory Provided Terminal Blocks per system)
MODEL
YCAL
VOLT HZ
SYSTEM #1 FIELD SUPPLIED WIRING
MCA
1
MIN
N/F
DISC
SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
SYSTEM #1 COMPRESSOR & FAN
TERMINAL
BLOCK
(std)
NF DISC.
SWITCH
(opt)
CIRCUIT
BREAKER
(opt)
COMPR. #1 COMPR. #2 COMPR. #3 FANS
MIN
3
MAX
4
MIN MAX
RLA LRA RLA LRA RLA LRA QTY FLA(EA)
0040
200 60 101 150 110 125 110 125 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 33.2 278 33.2 278 — — 2 8.2
230 60 94 100 110 125 110 125 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 33.2 278 33.2 278 — — 2 7.8
380 60 55 60 60 70 60 70 # 10 - # 1 # 14 - 1/0 # 14 - 2 19.9 151 19.9 151 — — 2 4.8
460 60 46 60 50 60 50 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 16.6 127 16.6 127 — — 2 4.0
575 60 36 60 40 45 40 45 # 10 - # 1 # 14 - 1/0 # 14 - 2 13.3 100 13.3 100 — — 2 3.1
0042
200 60 128 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 40.0 350 40.0 350 — — 2 8.2
230 60 119 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 40.0 350 40.0 350 — — 2 7.8
380 60 69 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 24.0 195 24.0 195 — — 2 4.8
460 60 58 60 70 70 70 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.9 167 19.9 167 — — 2 4.0
575 60 46 60 50 60 50 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 16.0 125 16.0 125 — — 2 3.1
0044
200 60 128 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 40.0 350 40.0 350 — — 2 8.2
230 60 119 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 40.0 350 40.0 350 — — 2 7.8
380 60 69 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 24.0 195 24.0 195 — — 2 4.8
460 60 58 60 70 70 70 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.9 167 19.9 167 — — 2 4.0
575 60 46 60 50 60 50 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 16.0 125 16.0 125 — — 2 3.1
0050
200 60 138 150 175 175 175 175 # 10 - 3/0 # 2 - 4/0 # 3 - 300 47.8 425 47.8 425 — — 2 8.2
230 60 128 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 3 - 300 47.8 425 47.8 425 — — 2 7.8
380 60 75 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 28.7 239 28.7 239 — — 2 4.8
460 60 62 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 23.9 198 23.9 198 — — 2 4.0
575 60 49 60 60 60 60 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 19.1 148 19.1 148 — — 2 3.1
0060
200 60 138 150 175 175 175 175 # 10 - 3/0 # 2 - 4/0 # 3 - 300 47.8 425 47.8 425 — — 2 8.2
230 60 128 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 3 - 300 47.8 425 47.8 425 — — 2 7.8
380 60 75 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 28.7 239 28.7 239 — — 2 4.8
460 60 62 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 23.9 198 23.9 198 — — 2 4.0
575 60 49 60 60 60 60 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 19.1 148 19.1 148 —- — 2 3.1
0064
200 60 178 200 200 225 200 225 # 10 - 300 # 3 - 300 # 3 - 300 40.0 350 40.0 350 40.0 350 2 8.2
230 60 165 200 200 200 200 200 # 10 - 300 # 3 - 300 # 3 - 300 40.0 350 40.0 350 40.0 350 2 7.8
380 60 96 150 110 110 110 110 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 24.0 195 24.0 195 24.0 195 2 4.8
460 60 79 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.9 167 19.9 167 19.9 167 2 4.0
575 60 63 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 16.0 125 16.0 125 16.0 125 2 3.1
0070
200 60 178 200 200 225 200 225 # 10 - 300 # 3 - 300 # 3 - 300 40.0 350 40.0 350 40.0 350 2 8.2
230 60 165 200 200 200 200 200 # 10 - 300 # 3 - 300 # 3 - 300 40.0 350 40.0 350 40.0 350 2 7.8
380 60 96 150 110 110 110 110 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 24.0 195 24.0 195 24.0 195 2 4.8
460 60 79 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.9 167 19.9 167 19.9 167 2 4.0
575 60 63 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 16.0 125 16.0 125 16.0 125 2 3.1
0074
200 60 192 250 225 225 225 225 # 10 - 300 # 3 - 300 # 3 - 300 47.8 425 47.8 425 47.8 425 2 8.2
230 60 178 200 200 225 200 225 # 10 - 300 # 3 - 300 # 3 - 300 47.8 425 47.8 425 47.8 425 2 7.8
380 60 103 150 125 125 125 125 # 10 - # 1 # 2 - 4/0 # 2 - 4/0 28.7 239 28.7 239 28.7 239 2 4.8
460 60 86 100 100 100 100 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 23.9 198 23.9 198 23.9 198 2 4.0
575 60 68 100 80 80 80 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.1 148 19.1 148 19.1 148 2 3.1
0080
200 60 192 250 225 225 225 225 # 10 - 300 # 3 - 300 # 3 - 300 47.8 425 47.8 425 47.8 425 2 8.2
230 60 178 200 200 225 200 225 # 10 - 300 # 3 - 300 # 3 - 300 47.8 425 47.8 425 47.8 425 2 7.8
380 60 103 150 125 125 125 125 # 10 - # 1 # 2 - 4/0 # 2 - 4/0 28.7 239 28.7 239 28.7 239 2 4.8
460 60 86 100 100 100 100 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 23.9 198 23.9 198 23.9 198 2 4.0
575 60 68 100 80 80 80 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.1 148 19.1 148 19.1 148 2 3.1
