Johnson Controls York YCAL0014E Series User Manual

YORK INTERNATIONAL
3
FORM 150.62-NM6 (LS1)
SYSTEM #2 FIELD SUPPLIED WIRING
MCA
1
MIN
N/F
DISC
SW
2
D.E. FUSE CKT. BKR.
5
INCOMING (LUGS) WIRE RANGE
6
SYSTEM #2 COMPRESSOR & FAN
TERMINAL
BLOCK
(std)
NF DISC.
SWITCH
(opt)
CIRCUIT
BREAKER
(opt)
COMPR. #1 COMPR. #2 COMPR. #3 FANS
MIN
3
MAX
4
MIN MAX
RLA LRA RLA LRA RLA LRA QTY FLA(EA)
101 150 110 125 110 125 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 37.4 278 37.4 278 — — 2 8.2
94 100 110 125 110 125 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 34.6 278 34.6 278 — — 2 7.8
55 60 60 70 60 70 # 10 - # 1 # 14 - 1/0 # 14 - 2 19.9 151 19.9 151 — — 2 4.8
46 60 50 60 50 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 16.5 127 16.5 127 — — 2 4.0
36 60 40 45 40 45 # 10 - # 1 # 14 - 1/0 # 14 - 2 13.2 100 13.2 100 — — 2 3.1
101 150 110 125 110 125 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 37.4 278 37.4 278 — — 2 8.2
94 100 110 125 110 125 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 34.6 278 34.6 278 — — 2 7.8
55 60 60 70 60 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.9 151 19.9 151 — — 2 4.8
46 60 50 60 50 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 16.5 127 16.5 127 — — 2 4.0
36 60 40 45 40 45 # 10 - # 1 # 14 - 1/0 # 14 - 2 13.2 100 13.2 100 — — 2 3.1
128 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 49.4 350 49.4 350 — — 2 8.2
119 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 45.8 350 45.8 350 — — 2 7.8
69 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 26.4 195 26.4 195 — — 2 4.8
58 60 70 70 70 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 21.8 158 21.8 158 — — 2 4.0
46 60 50 60 50 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 17.4 125 17.4 125 — — 2 3.1
128 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 49.4 350 49.4 350 — — 2 8.2
119 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 45.8 350 45.8 350 — — 2 7.8
69 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 26.4 195 26.4 195 — — 2 4.8
58 60 70 70 70 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 21.8 158 21.8 158 — — 2 4.0
46 60 50 60 50 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 17.4 125 17.4 125 — — 2 3.1
138 150 175 175 175 175 # 10 - 3/0 # 2 - 4/0 # 3 - 300 53.8 425 53.8 425 — — 2 8.2
128 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 3 - 300 49.8 425 49.8 425 — — 2 7.8
75 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 28.7 239 28.7 239 — — 2 4.8
62 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 23.7 187 23.7 187 — — 2 4.0
49 60 60 60 60 60 # 10 - # 1 # 14 - 1/0 # 14 - 2 19.0 148 19.0 148 — — 2 3.1
138 150 150 175 150 175 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 37.4 278 37.4 278 37.4 278 2 8.2
129 150 150 150 150 150 # 10 - 3/0 # 2 - 4/0 # 2 - 4/0 34.6 278 34.6 278 34.6 278 2 7.8
75 100 80 90 80 90 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.9 151 19.9 151 19.9 151 2 4.8
62 100 70 70 70 70 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 16.5 127 16.5 127 16.5 127 2 4.0
50 60 60 60 60 60 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 13.2 100 13.2 100 13.2 100 2 3.1
178 200 200 225 200 225 # 10 - 300 # 3 - 300 # 3 - 300 49.4 350 49.4 350 49.4 350 2 8.2
165 200 200 200 200 200 # 10 - 300 # 3 - 300 # 3 - 300 45.8 350 45.8 350 45.8 350 2 7.8
96 150 110 110 110 110 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 26.4 195 26.4 195 26.4 195 2 4.8
79 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 21.8 158 21.8 158 21.8 158 2 4.0
63 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 17.4 125 17.4 125 17.4 125 2 3.1
178 200 200 225 200 225 # 10 - 300 # 3 - 300 # 3 - 300 49.4 350 49.4 350 49.4 350 2 8.2
165 200 200 200 200 200 # 10 - 300 # 3 - 300 # 3 - 300 45.8 350 45.8 350 45.8 350 2 7.8
96 150 110 110 110 110 # 10 - # 1 # 14 - 1/0 # 2 - 4/0 26.4 195 26.4 195 26.4 195 2 4.8
79 100 90 100 90 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 21.8 158 21.8 158 21.8 158 2 4.0
63 100 70 80 70 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 17.4 125 17.4 125 17.4 125 2 3.1
192 250 225 225 225 225 # 10 - 300 # 3 - 300 # 3 - 300 53.8 425 53.8 425 53.8 425 2 8.2
178 200 200 225 200 225 # 10 - 300 # 3 - 300 # 3 - 300 49.8 425 49.8 425 49.8 425 2 7.8
103 150 125 125 125 125 # 10 - # 1 # 2 - 4/0 # 2 - 4/0 28.7 239 28.7 239 28.7 239 2 4.8
86 100 100 100 100 100 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 23.7 187 23.7 187 23.7 187 2 4.0
68 100 80 80 80 80 # 10 - # 1 # 14 - 1/0 # 14 - 1/0 19.0 148 19.0 148 19.0 148 2 3.1
