JOHNSON CONTROLS
86
FORM 150.62-NM6 (103)
Displays the programmed High Current Trip Voltage.
Displays the programmed High Current Trip Voltage.
Displays the Leaving and Return chilled liquid tem-
perature at the time of the fault.
Displays the programmed Setpoint and Range, if the
chiller is programmed for leaving chilled liquid control.
Displays the programmed Setpoint and Range, if the
chiller is programmed for return chilled liquid control.
Displays the Ambient Temp. at the time of the fault.
Displays which system is in the lead at the time of the
fault.
Displays status of the evaporator pump and heater at
the time of the fault.
Displays whether Remote Chiller Control was active
when the fault occurred.
S E T P O I N T = X X X . X ° F
R A N G E = + / - ° F
E V A P P U M P I S X X X
E V A P H E A T E R I S X X X
L E A D S Y S T E M I S
S Y S T E M N U M B E R X
A M B I E N T A I R T E M P
= X X X . X ° F
L C H L T = X X X . X ° F
R C H L T = X X X . X ° F
S Y S 2 T R I P V O L T S
= X . X V O L T S
S Y S 1 T R I P V O L T S
= X . X V O L T S
This is only displayed when the Current Feedback Op-
tion is one per unit.
Displays which compressors were running in the system
when the fault occurred.
Displays the system run time when the fault occurred.
Displays the system Suction and Discharge Pressure
of the time of the fault.
Displays the System Suction Temp and Saturated Suc-
tion Temp when an EEV is installed.
Displays the EEV signal % and Suction Superheat when
an EEV is installed.
System Inlet cooler temperature will be displayed only
on R-407c units.
Displays whether the System Liquid Line Solenoid or
Hot Gas Solenoid was energized at the time of the
fault.
S E T P O I N T = X X X . X ° F
R A N G E = + X X . X ° F
A C T I V E R E M O T E C T R L
X X X X
U N I T A C T U A L A M P S
= X X X . X A M P S
S Y S X S P = X X X X P S I G
D P = X X X X P S I G
S Y S X R U N T I M E
X X - X X - X X - X X D - H - M - S
S Y S X C O M P S T A T U S
1 = X X X 2 = X X X 3 = X X X
S Y S X L L S V I S X X X
H O T G A S S O L I S X X X
S Y S X C O O L E R I N L E T
R E F R I G T E M P = X X X . X ° F
Unit Controls
S Y S X S U C T = X X X . X ° F
S A T S U C T = X X X . X ° F
S Y S X E E V = X X X . X %
S U C T S H E A T = X X X . X ° F
