4-7
035-21786-100 Rev. 1 (0909)
Field Supplied
Unit below Remote Condenser
Unit Remote CondenserAbove
Double Riser
Field Supplied
YCRE
Unit
YCRE
Unit
YCRE
Unit
Receiver
Receiver
Receiver
Receiver
Oil Trap
Oil Trap
Oil Trap
Remote
Condenser
Liquid Loop
Liquid Loop
Liquid Loop
Remote
Condenser
Remote
Condenser
Remote
Condenser
At each
10 metres
At each
10 metres
At each
10 metres
Maximum
5 metres
Maximum
25 metres
Oil Trap
Oil Trap
Oil Trap
YCRE Refrigerant Piping Arrangements
