Johnson Controls YORK YLUA0078Z Series - Physical Data; TABLE 8 - Physical Data (English)

JOHNSON CONTROLS
44
FORM 150.73-NM1
ISSUE DATE: 07/03/2024
SECTION 5: TECHNICAL DATA
Physical data
YLUA0078_ – YLUA0158_
60 Hz
TABLE 8 - PHYSICAL DATA (ENGLISH)
REFRIGERANT R-410A AND
R-454B
MODEL NUMBER YLUA - STANDARD EFFICIENCY UNITS
GENERAL UNIT DATA 0078Zx 0088Zx 0095Zx 0098Zx 0108Zx 0130Zx 0148Zx 0158Zx
Length, in. 116.1 116.1 116.1 142.7 142.7 142.7 187.7 187.7
Width, in. 88.0 88.0 88.0 88.0 88.0 88.0 88.0 88.0
Height, in. 94.2 94.2 94.2 94.2 94.2 94.2 94.2 94.2
Number of refrigerant circuits 2 2 2 2 2 2 2 2
Oil charge, circuit 1/circuit 2,
gal (L)
2.58/2.58 3.28/2.58 3.28/2.76 2.76/2.76 3.28/3.33 3.33/3.33 4.99/2.76 4.99/3.33
Shipping weight, lb 3,941 3,941 3,941 4,747 4,838 4,929 6,172 6,263
Compressors, Scroll Type
Compressors per circuit 3/3 3/3 3/ 3 3/3 3/2 2/2 3/3 3/2
Compressors per unit 6 6 6 6 5 4 6 5
Nominal Tons Per Compressor
Circuit 1 13 15 15 15/32 15 32 32 32
Circuit 2 13 13 15/32 15/32 32 32 15/32 32
Condenser
Total face area ft
2
106.9 106.9 106.9 160.3 160.3 160.3 213.8 213.8
Number of rows 3 3 3 3 3 3 3 3
Fins per in. 17 17 17 17 17 17 17 17
Condenser Fans, Low Sound
Number of fans, circuit 1/circuit 2 2/2 2/2 2/2 3/3 2/4 3/3 4/4 4/4
Fan HP 2 2 2 2 2 2 2 2
Fan rpm 1,160 1,160 1,160 1,160 1,160 1,160 1,160 1,160
Total chiller CFM 62,400 62,400 62,400 93,600 93,600 93,600 12,800 12,800
