Johnson Controls YORK YLUA0078Z Series - TABLE 29 - High Efficiency Unit Electrical Data (5 Compr) R-454 B, Dual Point; TABLE 30 - High Efficiency Unit Electrical Data (6 Compr) R-454 B, Dual Point

JOHNSON CONTROLS
60
FORM 150.73-NM1
ISSUE DATE: 07/03/2024
SECTION 5: TECHNICAL DATA
MODEL EFF
VOLT
Code
System 1 System 2 SYSTEM # 1 SYSTEM # 2
MCA
MIN N/
FDS
MIN
DUAL
ELEM
FUSE and
MIN CB
MAX
DUAL
ELEM
FUSE and
MAX CB
MCA
MIN N/F
DS
MIN
DUAL
ELEM
FUSE and
MIN CB
MAX
DUAL
ELEM
FUSE and
MAX CB
COMPR 1 COMPR 2 COMPR 3 COND FANS COMPR 1 COMPR 2 COMPR 3 COND FANS
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0095 SE
17 203 - - 250 203 - - 250 57.7 284 57.7 284 57.7 284 2 7.6 44.0 57.7 284 57.7 284 57.7 284 2 7.6 44.0
23 202 - - 250 202 - - 250 57.7 330 57.7 330 57.7 330 2 7.4 37.0 57.7 330 57.7 330 57.7 330 2 7.4 37.0
40 109 - - 125 109 - - 125 30.9 192 30.9 192 30.9 192 2 4.5 23.1 30.9 192 30.9 192 30.9 192 2 4.5 23.1
46 95 - - 110 95 - - 110 26.9 180 26.9 180 26.9 180 2 4.0 19.0 26.9 180 26.9 180 26.9 180 2 4.0 19.0
58 76 - - 90 76 - - 90 21.5 132 21.5 132 21.5 132 2 2.9 15.3 21.5 132 21.5 132 21.5 132 2 2.9 15.3
0148 SE
17 376 – – 450 218 – – 250 106.2 652 106.2 652 106.2 652 4 7.6 44.0 57.7 284 57.7 284 57.7 284 4 7.6 44.0
23 375 – – 450 217 – – 250 106.2 652 106.2 652 106.2 652 4 7.4 37.0 57.7 330 57.7 330 57.7 330 4 7.4 37.0
40 227 – – 250 118 – – 125 64.3 355 64.3 355 64.3 355 4 4.5 23.1 30.9 192 30.9 192 30.9 192 4 4.5 23.1
46 189 – – 225 103 – – 125 53.1 316 53.1 316 53.1 316 4 4.0 19.0 26.9 180 26.9 180 26.9 180 4 4.0 19.0
58 150 – – 175 81 – – 100 42.5 255 42.5 255 42.5 255 4 2.9 15.3 21.5 132 21.5 132 21.5 132 4 2.9 15.3
TABLE 29 - HIGH EFFICIENCY UNIT ELECTRICAL DATA (5 COMPR) R-454B, DUAL POINT
MODEL EFF
VOLT
Code
System 1 System 2 SYSTEM # 1 SYSTEM # 2
MCA
MIN N/
FDS
MIN
DUAL
ELEM
FUSE and
MIN CB
MAX
DUAL
ELEM
FUSE and
MAX CB
MCA
MIN N/F
DS
MIN
DUAL
ELEM
FUSE and
MIN CB
MAX
DUAL
ELEM
FUSE and
MAX CB
COMPR 1 COMPR 2 COMPR 3 COND FANS COMPR 1 COMPR 2 COMPR 3 COND FANS
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0108 HE
17 203 – – 250 269 – – 350 57.7 284 57.7 284 57.7 284 2 7.6 44.0 106.2 652 106.2 652 – – 4 7.6 44.0
23 202 – – 250 269 – – 350 57.7 330 57.7 330 57.7 330 2 7.4 37.0 106.2 652 106.2 652 – – 4 7.4 37.0
40 109 – – 125 163 – – 225 30.9 192 30.9 192 30.9 192 2 4.5 23.1 64.3 355 64.3 355 – – 4 4.5 23.1
46 95 – – 110 135 – – 175 26.9 180 26.9 180 26.9 180 2 4.0 19.0 53.1 316 53.1 316 – – 4 4.0 19.0
58 76 – – 90 107 – – 125 21.5 132 21.5 132 21.5 132 2 2.9 15.3 42.5 255 42.5 255 – – 4 2.9 15.3
TABLE 30 - HIGH EFFICIENCY UNIT ELECTRICAL DATA (6 COMPR) R-454B, DUAL POINT
MODEL EFF
VOLT
Code
System 1 System 2 SYSTEM # 1 SYSTEM # 2
MCA
MIN N/
FDS
MIN
DUAL
ELEM
FUSE and
MIN CB
MAX
DUAL
ELEM
FUSE and
MAX CB
MCA
MIN N/F
DS
MIN
DUAL
ELEM
FUSE and
MIN CB
MAX
DUAL
ELEM
FUSE and
MAX CB
COMPR 1 COMPR 2 COMPR 3 COND FANS COMPR 1 COMPR 2 COMPR 3 COND FANS
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0098 HE
17 210 – – 250 210 – – 250 57.7 284 57.7 284 57.7 284 3 7.6 44.0 57.7 284 57.7 284 57.7 284 3 7.6 44.0
23 210 – – 250 210 – – 250 57.7 330 57.7 330 57.7 330 3 7.4 37.0 57.7 330 57.7 330 57.7 330 3 7.4 37.0
40 114 – – 125 114 – – 125 30.9 192 30.9 192 30.9 192 3 4.5 23.1 30.9 192 30.9 192 30.9 192 3 4.5 23.1
46 99 – – 125 99 – – 125 26.9 180 26.9 180 26.9 180 3 4.0 19.0 26.9 180 26.9 180 26.9 180 3 4.0 19.0
58 79 – – 100 79 – – 100 21.5 132 21.5 132 21.5 132 3 2.9 15.3 21.5 132 21.5 132 21.5 132 3 2.9 15.3
TABLE 28 - STANDARD EFFICIENCY UNIT ELECTRICAL DATA (6 COMPR) R-454B, , DUAL POINT, CONT’D
