SECTION 5: TECHNICAL DATA
TABLE 16 - STANDARD EFFICIENCY UNIT ELECTRICAL DATA (4 COMPR) R-454B, SINGLE POINT
MODEL EFF.
PUMP
MOD-
EL
VOLT
CODE
PUMP
FLA
MCA
MIN
N/F
DS
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX
CB
SYSTEM # 1 SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 FAN COMPR 1 COMPR 2 COMPR 3 FAN
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0130 SE X
17 - 497 - - 600 106.2 652 106.2 652 - - 3 7.6 44.0 106.2 652 106.2 652 - - 3 7.6 44.0
23 - 496 - - 600 106.2 652 106.2 652 - - 3 7.4 37.0 106.2 652 106.2 652 - - 3 7.4 37.0
40 - 300 - - 350 64.3 355 64.3 355 - - 3 4.5 23.1 64.3 355 64.3 355 - - 3 4.5 23.1
46 - 250 - - 300 53.1 316 53.1 316 - - 3 4.0 19.0 53.1 316 53.1 316 - - 3 4.0 19.0
58 - 198 - - 250 42.5 255 42.5 255 - - 3 2.9 15.3 42.5 255 42.5 255 - - 3 2.9 15.3
TABLE 17 - STANDARD EFFICIENCY UNIT ELECTRICAL DATA (5 COMPR) R-454B, SINGLE POINT
MODEL EFF.
Pump
Model
Volt
Code
Pump
FLA
MCA
MIN
N/F
DS
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX
CB
SYSTEM # 1 SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 FAN COMPR 1 COMPR 2 COMPR 3 FAN
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0158 SE X
17 - 618 - - 700 106.2 652 106.2 652 106.2 652 4 7.6 44.0 106.2 652 106.2 652 - - 4 7.6 44.0
23 - 617 - - 700 106.2 652 106.2 652 106.2 652 4 7.4 37.0 106.2 652 106.2 652 - - 4 7.4 37.0
40 - 374 - - 400 64.3 355 64.3 355 64.3 355 4 4.5 23.1 64.3 355 64.3 355 - - 4 4.5 23.1
46 - 311 - - 350 53.1 316 53.1 316 53.1 316 4 4.0 19.0 53.1 316 53.1 316 - - 4 4.0 19.0
58 - 246 - - 250 42.5 255 42.5 255 42.5 255 4 2.9 15.3 42.5 255 42.5 255 - - 4 2.9 15.3
TABLE 18 - STANDARD EFFICIENCY UNIT ELECTRICAL DATA (6 COMPR) R-454B, SINGLE POINT
MODEL E󰀨.
Pump
Model
Volt
Code
Pump
FLA
MCA
MIN
N/F DS
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX
CB
SYSTEM # 1 SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 COMPR 3 FAN COMPR 1 COMPR 2 COMPR 3 FAN
RLA LRA RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA RLA LRA QTY FLA LRA
0078 SE X
17 - 334 - - 350 48.5 257 48.5 257 48.5 257 2 7.6 44.0 48.5 257 48.5 257 48.5 257 2 7.6 44.0
23 - 333 - - 350 48.5 288 48.5 288 48.5 288 2 7.4 37.0 48.5 288 48.5 288 48.5 288 2 7.4 37.0
40 - 191 - - 200 27.6 172 27.6 172 27.6 172 2 4.5 23.1 27.6 172 27.6 172 27.6 172 2 4.5 23.1
46 - 169 - - 175 24.4 145 24.4 145 24.4 145 2 4.0 19.0 24.4 145 24.4 145 24.4 145 2 4.0 19.0
58 - 120 - - 125 17.4 114 17.4 114 17.4 114 2 2.9 15.3 17.4 114 17.4 114 17.4 114 2 2.9 15.3
0088 SE X
17 - 363 - - 400 57.7 284 57.7 284 57.7 284 2 7.6 44.0 48.5 257 48.5 257 48.5 257 2 7.6 44.0
23 - 363 - - 400 57.7 330 57.7 330 57.7 330 2 7.4 37.0 48.5 288 48.5 288 48.5 288 2 7.4 37.0
40 - 201 - - 225 30.9 192 30.9 192 30.9 192 2 4.5 23.1 27.6 172 27.6 172 27.6 172 2 4.5 23.1
46 - 177 - - 200 26.9 180 26.9 180 26.9 180 2 4.0 19.0 24.4 145 24.4 145 24.4 145 2 4.0 19.0
58 - 134 - - 150 21.5 132 21.5 132 21.5 132 2 2.9 15.3 17.4 114 17.4 114 17.4 114 2 2.9 15.3
