Johnson Controls YORK - Page 27

Table 7: Condenser shell weights – 150# design, no hot gas bypass, no water boxes, 0.025
tubes
Shell code Weight Kgs
Q2 11200 24640
Q3 12000 26400
Q4 12900 28380
QQ 12900 28380
QR 13600 29920
QS 14200 31240
R2 13100 28820
R3 13900 30580
R4 14900 32780
RQ 15500 34100
RR 16200 35640
RS 16700 36740
LB 18400 40480
LCL 19300 42460
LD 23900 52580
L2 15100 33220
L3 16100 35420
L4 17200 37840
MB 20200 44440
MC 21800 47960
MD 23200 51040
M2 17700 38940
M3 18900 41580
M4 20200 44440
BB 21000 46200
BC 21100 46420
BD 22600 49720
BE 23200 51040
B2 17300 38060
B3 18100 39820
B4 18800 41360
B5 19700 43340
CB 28900 63580
CC 30400 66880
CD 32500 71500
C2 23100 50820
C3 25400 55880
C4 27800 61160
DB 31400 69080
25Centrifugal Liquid Chillers
