Table 7: Condenser shell weights – 150# design, no hot gas bypass, no water boxes, 0.025
tubes
Shell code Weight Kgs
DC 32900 72380
DD 34300 75460
DE 35100 77220
D2 27100 59620
D3 28100 61820
D4 28900 63580
D5 30300 66660
EB 35700 78540
EC 37600 82720
ED 36400 80080
EE 40200 88440
E2 30500 67100
E3 31600 69520
E4 32700 71940
E5 34400 75680
FB 35500 78100
FC 37200 81840
FD 38500 84700
FE 39300 86460
F2 30500 67100
F3 31500 69300
F4 32700 71940
F5 34000 74800
KB 49900 109780
KC 52400 115280
KD 53900 118580
KE 55200 121440
K2 42000 92400
K3 43500 95700
K4 45100 99220
K5 47400 104280
