Johnson Controls ZY Series User Manual

Table 84: ZYA7 Charging Table
Air Flow Indoor Db/Wb Outdoor DB Suction P Suction Temp. Liquid P Liquid Temp. Delta T Db Compr. amps
75 133 61 262 77 -25 10.8
85 132 60 305 86 -26 12.0300 Cfm/Ton 80/62
95 132 58 349 96 -26 13.3
75 134 60 262 78 -25 10.8
85 137 60 306 87 -24 12.1300 Cfm/Ton 80/67
95 140 60 350 96 -23 13.3
75 135 59 263 79 -25 10.8
85 141 60 306 88 -22 12.1300 Cfm/Ton 80/72
95 147 62 350 97 -20 13.4
75 127 57 261 77 -23 10.7
85 129 57 305 86 -23 12.0300 Cfm/Ton 75/62
95 130 57 350 96 -22 13.3
75 136 64 263 77 -23 10.8
85 138 63 306 86 -23 12.1400 Cfm/Ton 80/62
95 140 62 350 96 -22 13.3
75 138 64 264 77 -22 10.8
85 141 63 308 87 -21 12.1400 Cfm/Ton 80/67
95 145 62 352 96 -21 13.4
75 140 64 265 78 -21 10.8
85 145 63 309 87 -20 12.2400 Cfm/Ton 80/72
95 149 61 354 97 -19 13.5
75 131 60 261 77 -20 10.7
85 134 60 305 86 -20 12.0
400 Cfm/Ton 75/62
95 136 60 350 96 -19 13.3
Table 85: ZY08 Charging Table System 1
Air Flow Indoor Db/Wb Outdoor DB Suction P Suction Temp. Liquid P Liquid Temp. Delta T Db Compr. amps
75 139 60 271 83 -25 7.0
85 138 58 319 91 -26 7.9300 Cfm/Ton 80/62
95 137 57 367 98 -27 8.8
75 139 60 270 85 -25 7.0
85 143 59 318 94 -24 7.9300 Cfm/Ton 80/67
95 146 58 365 103 -23 8.8
75 140 59 269 87 -25 7.0
85 148 59 317 97 -23 7.9300 Cfm/Ton 80/72
95 155 59 364 107 -20 8.8
75 133 56 270 83 -23 7.0
85 133 55 318 91 -23 7.9300 Cfm/Ton 75/62
95 134 55 365 99 -23 8.8
75 144 62 272 84 -23 7.0
85 145 62 320 92 -23 7.9400 Cfm/Ton 80/62
95 147 61 367 101 -23 8.8
75 145 62 271 86 -23 7.0
85 148 62 319 94 -22 7.9400 Cfm/Ton 80/67
95 151 62 367 102 -21 8.8
75 147 63 269 88 -22 7.0
85 151 62 318 96 -21 7.9400 Cfm/Ton 80/72
95 155 62 367 104 -19 8.8
75 138 59 271 83 -21 7.0
85 140 58 319 91 -20 7.9
400 Cfm/Ton 75/62
95 142 58 367 100 -19 8.8
INSTALLATION MANUAL ZY SERIES 3-10ton 60 Hertz R-410A134
