Johnson Controls ZY Series User Manual

Table 9: ZY04 to 12 Standard Static Indoor Blower - Without Powered Convenience Outlet
Compressor 1 Compressor 2
Electric Heat Field
Installed Kit 2EK045*
4
Min Disconnect Rating
Min Disconnect Rating/ Pwr Exh Size (Tons) Nominal Unit Voltage
RLA LRA MCC RLA LRA MCC
OD Fan Motors (each) Supply Blower Motor Pwr Exh Motor Pwr Conv Outlet
Model kW Stages Amps
1
MCA (Amps)
2,3
Min Fuse/ Breaker Size (Amps)
Max Fuse/ Breaker Size (Amps)
FLA LRA
MCA w/Pwr Exh (Amps) Min Fuse/ Breaker Size w/ Pwr Exh (Amps) Max Fuse/ Breaker Size w/ Pwr Exh (Amps)
FLA LRA
None - - - 47 50 60 49 264 49.2 50 60 52 274
11725 12 1 33.3 48.1 50 60 49 264 50.9 60 60 52 274
12525 18.6 1 51.6 71 80 80 65 264 73.8 80 80 68 274
13225 24 1 66.6 89.8 90 90 83 264 92.5 100 100 85 274
208-3-60 16 110 25 16 110 25 5.8 5.2 1.1
14225 31.8 2 88.3 116.9 125 125 108 264 119.6 125 125 110 274
None - - - 46.4 50 60 49 264 48.4 50 60 51 269
11725 16 1 38.5 54.6 60 60 50 264 57.1 60 60 53 269
12525 24.8 1 59.7 81.1 90 90 75 264 83.6 90 90 77 269
13225 32 1 77 102.8 110 110 95 264 105.3 110 110 97 269
230-3-60 16 110 25 16 110 25 5.2 5.2 1
14225 42.4 2 102 134 150 150 123 264 136.5 150 150 126 269
None - - - 23.1 25 30 24 128 24.1 25 30 25 130
11746 16.5 1 19.8 28 30 30 26 128 29.3 30 30 27 130
12846 27.8 1 33.4 45 45 45 41 128 46.3 50 50 43 130
13346 33 1 39.7 52.9 60 60 49 128 54.1 60 60 50 130
460-3-60 7.8 52 12 7.8 52 12 2.9 2.6 0.5
14246 41.7 2 50.2 66 70 70 61 128 67.3 70 70 62 130
None - - - 17 20 20 18 99 17.8 20 20 19 101
11758 17 1 16.4 23 25 25 21 99 24 25 25 22 101
12 (10)
575-3-60 5.7 38.9 9 5.7 38.9 9 2.2 2 0.4
13458 34 1 32.7 43.4 45 45 40 99 44.4 45 45 41 101
With VFD
None - - - 33.6 35 50 34 206 35.8 40 50 36 211
10725 4.9 1 13.6 33.6 35 50 34 206 35.8 40 50 36 211
11725 12 1 33.3 50.4 60 60 46 206 53.1 60 60 49 211
208-3-60 17.6 136 27 2.3 7 1.1
12525 18.6 1 51.6 73.3 80 80 67 206 76 80 80 70 211
None - - - 33.8 35 50 34 208 35.8 40 50 36 212
10725 6.5 1 15.6 33.8 35 50 34 208 35.8 40 50 36 212
11725 16 1 38.5 57.1 60 60 53 208 59.6 60 60 55 212
230-3-60 17.6 136 27 2.3 7.2 1
12525 24.8 1 59.7 83.6 90 90 77 208 86.1 90 90 79 212
None - - - 16.8 20 25 17 103 17.8 20 25 18 105
10746 6 1 7.2 16.8 20 25 12 103 17.8 20 25 14 105
11746 16.5 1 19.8 29.3 30 30 27 103 30.5 35 35 28 105
460-3-60 8.5 66.1 13 1.3 3.6 0.5
12646 25.5 1 30.7 42.9 45 45 39 103 44.1 45 45 41 105
None - - - 12.6 15 15 13 78 13.4 15 15 14 80
11758 17 1 16.4 23.6 25 25 22 78 24.6 25 25 23 80
A7 (6)
575-3-60 6.3 55.3 10 1.1 2.5 0.4
12658 25.7 1 24.7 34 35 35 31 78 35 35 35 32 80
INSTALLATION MANUAL ZY SERIES 3-10ton 60 Hertz R-410A32
