Johnson Controls ZY Series User Manual

Table 9: ZY04 to 12 Standard Static Indoor Blower - Without Powered Convenience Outlet
Compressor 1 Compressor 2
Electric Heat Field
Installed Kit 2EK045*
4
Min Disconnect Rating
Min Disconnect Rating/ Pwr Exh Size (Tons) Nominal Unit Voltage
RLA LRA MCC RLA LRA MCC
OD Fan Motors (each) Supply Blower Motor Pwr Exh Motor Pwr Conv Outlet
Model kW Stages Amps
1
MCA (Amps)
2,3
Min Fuse/ Breaker Size (Amps)
Max Fuse/ Breaker Size (Amps)
FLA LRA
MCA w/Pwr Exh (Amps) Min Fuse/ Breaker Size w/ Pwr Exh (Amps) Max Fuse/ Breaker Size w/ Pwr Exh (Amps)
FLA LRA
None - - - 48.8 50 60 52 302 51 60 60 54 312
11725 12 1 33.3 50.4 60 60 52 302 53.1 60 60 54 312
12525 18.6 1 51.6 73.3 80 80 67 302 76 80 80 70 312
13225 24 1 66.6 92 100 100 85 302 94.8 100 100 87 312
208-3-60 16 110 25 16 110 25 5.8 7 1.1
14225 31.8 2 88.3 119.1 125 125 110 302 121.9 125 125 112 312
None - - - 48.4 50 60 51 301 50.4 60 60 53 305
11725 16 1 38.5 57.1 60 60 53 301 59.6 60 60 55 305
12525 24.8 1 59.7 83.6 90 90 77 301 86.1 90 90 79 305
13225 32 1 77 105.3 110 110 97 301 107.8 110 110 99 305
230-3-60 16 110 25 16 110 25 5.2 7.2 1
14225 42.4 2 102 136.5 150 150 126 301 139 150 150 128 305
None - - - 24.1 25 30 25 146 25.1 30 30 27 148
11746 16.5 1 19.8 29.3 30 30 27 146 30.5 35 35 28 148
12846 27.8 1 33.4 46.3 50 50 43 146 47.5 50 50 44 148
13346 33 1 39.7 54.1 60 60 50 146 55.4 60 60 51 148
460-3-60 7.8 52 12 7.8 52 12 2.9 3.6 0.5
14246 41.7 2 50.2 67.3 70 70 62 146 68.5 70 70 63 148
None - - - 17.5 20 20 19 107 18.3 20 20 19 109
11758 17 1 16.4 23.6 25 25 22 107 24.6 25 25 23 109
12 (10)
575-3-60 5.7 38.9 9 5.7 38.9 9 2.2 2.5 0.4
13458 34 1 32.7 44 45 45 40 107 45 45 45 41 109
1 Minimum Circuit Ampacity.
2 Dual Element, Time Delay Type.
3 HACR type per NEC.
4 Non-fused Disconnect. Verify on the unit nameplate that the disconnect is properly sized for the application. Units with field
installed electric heat kits may exceed the factory installed disconnect amperage rating.
INSTALLATION MANUAL ZY SERIES 3-10ton 60 Hertz R-410A34
Johnson Controls Ducted Systems

Johnson Controls ZY Series Specifications

General

Brand	Johnson Controls
Model	ZY Series
Category	Air Conditioner
Language	English
