Johnson 5300 Series - Receiver;Exciter Assembly (Version A;B)

PARTS LIST
7-3
NOTE: Refer to Section 1.12 for version information.
CR 001 10V zener SOT-23 523-2016-100
CR 002 Switching diode SOT-23 523-1504-002
J 201 Connector, 20-pin 515-7111-230
J 202 Connector, 30-pin 515-7106-430
L 001 270 nH smd inductor 542-9017-274
L 002 270 nH smd inductor 542-9017-274
L 003 270 nH smd inductor 542-9017-274
P 100 Header, 2-pin friction lock 515-9031-201
P 101 Header, 3-pin friction lock 515-9031-202
P 102 Header, 3-pin friction lock 515-9031-202
PC 001 PC board, interface revision 2
035-5500-200 2
Q 001 NPN general purpose 576-0003-658
Q 002 NPN general purpose 576-0003-658
Q 003 NPN general purpose 576-0003-658
Q 004 NPN general purpose 576-0003-658
R 002 2.2 ohm ±5% 1W smd 569-0175-229
R 003 10k ohm ±5% 1/8W smd 569-0105-103
R 004 47k ohm ±5% 1/8W smd 569-0105-473
R 005 10k ohm ±5% 1/8W smd 569-0105-103
R 006 7.5k ohm ±5% 1/8W smd 569-0105-752
R 008 1k ohm ±5% 1/8W smd 569-0115-102
R 009 1k ohm ±5% 1/8W smd 569-0115-102
R 010 1k ohm ±5% 1/8W smd 569-0115-102
R 011 39k ohm ±5% 1/8W smd 569-0155-393
R 012 12k ohm ±5% 1/8W smd 569-0155-123
R 013 10k ohm ±5% 1/8W smd 569-0115-103
R 014 10k ohm ±5% 1/8W smd 569-0115-103
R 015 Zero ohm jumper 569-0115-001
R 016 10k ohm ±5% 1/8W smd 569-0115-103
R 017 3k ohm ±5% 1/8W smd 569-0115-302
R 018 10k ohm ±5% 1/8W smd 569-0115-103
R 019 Zero ohm jumper 569-0115-001
R 020 10k ohm ±5% 1/8W smd 569-0115-103
R 021 10k ohm ±5% 1/8W smd 569-0115-103
R 022 10k ohm ±5% 1/8W smd 569-0105-103
R 023 12k ohm ±5% 1/8W smd 569-0115-123
R 024 12k ohm ±5% 1/8W smd 569-0155-123
R 025 20k ohm ±5% 1/8W smd 569-0155-203
R 026 13k ohm ±5% 1/8W smd 569-0155-133
R 027 10k ohm ±5% 1/8W smd 569-0115-103
Ref No. Description Part No.
R 028 100k ohm ±5% 1/8W smd 569-0115-104
R 029 100k ohm ±5% 1/8W smd 569-0115-104
R 030 100k ohm ±5% 1/8W smd 569-0115-104
R 031 10k ohm ±5% 1/8W smd 569-0115-103
R 032 10k ohm ±5% 1/8W smd 569-0115-103
R 033 10k ohm ±5% 1/8W smd 569-0115-103
R 034 10k ohm ±5% 1/8W smd 569-0115-103
R 035 10k ohm ±5% 1/8W smd 569-0115-103
R 036 10k ohm ±5% 1/8W smd 569-0115-103
R 037 39k ohm ±5% 1/8W smd 569-0155-393
R 038 470 ohm ±5% 1/8W smd 569-0155-471
R 039 10k ohm ±5% 1/8W smd 569-0155-103
R 040 470 ohm ±5% 1/8W smd 569-0155-471
R 041 10k ohm ±5% 1/8W smd 569-0155-103
U 001 Audio amp, 22W TDA1519 544-2004-003
U 002 Voltage regulator, adj REG103UA 544-2603-057
U 003 Op amp, dual LM2904 544-2019-004
U 004 Dig potentiometer, 2-ch AD8402 544-0004-213
U 006 Voltage regulator, adj REG103UA 544-2603-057
U 007 Multiplexer, triple 4053 544-1014-053
U 008 Voltage regulator, adj REG103UA 544-2603-057
U 009 CPLD prog logic device XC2C64 544-5001-420
U 010 Op amp, dual LM2904 544-2019-004
RECEIVER/EXCITER ASSEMBLY
(VERSION A/B)
Part No. 023-53x7-202/-212
A 001 Interconnect board assy, unrevised
(see separate listing which follows)
023-5300-050
Interconnect board assy, revised
(see separate listing which follows)
023-5300-055
A 002 RF board assembly, VHF unrevised 585-0400-003
RF board assembly, VHF revised 585-5100-003
RF board assy, UHF unrevised 587-0400-005
RF board assy, UHF revised 585-5100-005
RF board assy, 800 MHz unrevised 587-5000-003
RF board assy, 800 MHz revised 585-5100-009
A 216 Flex circuit, revised RF to logic bd 035-5100-050
EP 001 0.2 x 0.2 fish paper 018-1080-020
HW 001 Screw, 2-56 x 3/16 pan hd 575-1602-006
HW 002 Screw, 4-40 x 1/4 pan hd 575-1604-008
Ref No. Description Part No.
Receiver/Exciter AssemblyInterface Board Assembly (Version C)
