PARTS LIST
7-12
NOTE: Refer to Section 1.12 for version information.
R 539 68k ohm ±5% 1/8W smd 569-0105-683
R 540 4.3k ohm ±5% 1/8W smd 569-0105-432
R 541 330 ohm ±5% 1/8W smd 569-0105-331
R 542 6.2k ohm ±5% 1/8W smd 569-0105-622
R 543 220 ohm ±5% 1/8W smd 569-0105-221
R 544 220k ohm ±5% 1/8W smd 569-0105-224
R 545 220k ohm ±5% 1/8W smd 569-0105-224
R 546 1.0k ohm ±5% 1/8W smd 569-0105-102
R 547 1.0k ohm ±5% 1/8W smd 569-0105-102
R 548 10k ohm ±5% 1/8W smd 569-0105-103
R 549 18k ohm ±5% 1/8W smd 569-0105-183
R 550 20k ohm ±5% 1/8W smd 569-0105-203
R 551 68k ohm ±5% 1/8W smd 569-0105-683
R 552 820 ohm ±5% 1/8W smd 569-0105-821
R 553 200 ohm ±5% 1/8W smd 569-0115-201
R 554 .030 ohm ±5% 2W wirewound 569-2019-307
R 555 200 ohm ±5% 1/8W smd 569-0115-201
R 556 470 ohm ±5% 1/8W smd 569-0105-471
R 557 4.7k ohm ±5% 1/8W smd 569-0115-472
R 558 18k ohm ±5% 1/8W smd 569-0105-183
R 559 10k ohm ±5% 1/8W smd 569-0105-103
R 560 68k ohm ±5% 1/8W smd 569-0105-683
R 561 20k ohm ±5% 1/8W smd 569-0105-203
R 562 18 ohm ±5% 1/8W smd 569-0115-180
R 563 470 ohm ±5% 1W smd 569-0175-471
R 564 470 ohm ±5% 1W smd 569-0175-471
R 565 680 ohm ±5% 1/8W smd 569-0105-681
R 566 470 ohm ±5% 1W smd 569-0175-471
R 567 100 ohm ±5% .75W smd 569-0135-101
R 568 300 ohm ±5% +/- 400 PPM smd 569-0116-301
R 569 300 ohm ±5% +/- 400 PPM smd 569-0116-301
R 570 18k ohm ±5% 1/8W smd 569-0105-183
R 571 68k ohm ±5% 1/8W smd 569-0105-683
R 572 330 ohm ±5% 1/8W smd 569-0105-331
R 573 68k ohm ±5% 1/8W smd 569-0105-683
R 574 10k ohm ±5% thermistor 569-3013-007
R 575 18k ohm ±5% 1/8W smd 569-0105-183
R 576 100 ohm ±5% 1/8W smd 569-0105-101
R 577 100k ohm ±5% 1/8W smd 569-0105-104
R 578 1.2k Ohm J 1206smd Rl 569-0115-122
R 579 1.2k Ohm J 1206smd Rl 569-0115-122
R 580 1.2k Ohm J 1206smd Rl 569-0115-122
R 581 560 ohm ±5% 1/8W smd 569-0105-561
R 582 Zero ohm ±5% 1/8W smd 569-0105-001
R 583 Zero ohm ±5% 1/8W smd 569-0105-001
Ref No. Description Part No.
R 584 Zero ohm ±5% 1/8W smd 569-0105-001
U 501 Shift register, 8-stage MC4094 544-3016-094
U 502 Op amp, dual LM2904 544-2019-004
U 505 Current sense amp MAX472ESA 544-2039-002
U 507 Op amp, dual LM2904 544-2019-004
U 508 Regulator, 8V 3A MC78TO8CT 544-2003-095
UHF 40W PA BOARD ASSEMBLY
Part No. 023-5365-501
C 002 240 pF, ±5%, high Q, smd 510-3667-241
C 003 240 pF, ±5%, high Q, smd 510-3667-241
C 004 8.2 pF, ±5%, high Q, 0805 510-3667-829
C 005 27 pF, ±1%, high Q, 0805 510-3661-270
C 006 27 pF, ±1%, high Q, 0805 510-3661-270
C 007 47 pF, ±1%, high Q, 0805 510-3661-470
C 008 47 pF, ±1%, high Q, 0805 510-3661-470
C 014 27 pF, ±1%, high Q, 0805 510-3661-270
C 015 27 pF, ±1%, high Q, 0805 510-3661-270
C 017 5.1 pF, ±.1 pF, high Q, smd 510-3667-519
C 018 150 pF, ±5%, high Q, smd 510-3667-151
C 020 10 pF, ±1%, high Q, 0805 510-3661-100
C 021 10 pF, ±1%, high Q, 0805 510-3661-100
C 022 56 pF, ±5%, high Q, 0805 510-3667-560
C 026 27 pF, ±1%, high Q, 0805 510-3661-270
C 027 27 pF, ±1%, high Q, 0805 510-3661-270
C 028 3.9 pF, ±.1 pF, high Q, smd 510-3667-399
C 029 3.9 pF, ±.1 pF, high Q, smd 510-3667-399
C 030 5.1 pF, ±.1 pF, high Q, smd 510-3667-519
C 106 150 pF ±5% NPO 1206 smd 510-3601-151
C 107 150 pF ±5% NPO 1206 smd 510-3601-151
C 108 150 pF ±5% NPO 1206 smd 510-3601-151
C 109 150 pF ±5% NPO 1206 smd 510-3601-151
C 111 150 pF ±5% NPO 1206 smd 510-3601-151
C 112 150 pF, ±1%, high Q, 0805 510-3661-151
C 113 150 pF, ±1%, high Q, 0805 510-3661-151
C 124 150 pF, ±5%, high Q, smd 510-3667-151
C 125 .018 µF ±10% X7R 50V cer smd 510-3605-183
C 126 6.8 µF 35V tantalum smd 510-2635-689
C 127 .001 µF ±5% NPO 1206 smd 510-3602-102
C 128 150 pF, ±5%, high Q, smd 510-3667-151
C 129 .018 µF ±10% X7R 50V cer smd 510-3605-183
C 130 6.8 µF 35V tantalum smd 510-2635-689
C 131 150 pF ±5% NPO 50V cer smd 510-3601-151
Ref No. Description Part No.
UHF 40W PA Board AssemblyUHF 15W PA Board Assembly (Cont’d)
To Next Page
