Johnson 5300 Series - Page 86

PARTS LIST
7-13
NOTE: Refer to Section 1.12 for version information.
C 132 .0047 µF ±10% smd 510-3606-472
C 133 6.8 µF 35V tantalum smd 510-2635-689
C 141 6.8 µF 35V tantalum smd 510-2635-689
C 142 .0047 µF ±10% smd 510-3606-472
C 143 150 pF ±5% NPO 50V cer smd 510-3601-151
C 144 150 pF, ±5%, high Q, smd 510-3667-151
C 145 .018 µF ±10% X7R 50V cer smd 510-3605-183
C 146 6.8 µF 35V tantalum smd 510-2635-689
C 147 .001 µF ±5% NPO 1206 smd 510-3602-102
C 148 6.8 µF 35V tantalum smd 510-2635-689
C 149 .018 µF ±10% X7R 50V cer smd 510-3605-183
C 150 150 pF ±5% NPO 50V cer smd 510-3601-151
C 151 150 pF ±5% NPO 50V cer smd 510-3601-151
C 152 150 pF ±5% NPO 50V cer smd 510-3601-151
C 153 .018 µF ±10% X7R 50V cer smd 510-3605-183
C 154 470 µF 16V electrolytic 510-4056-471
C 161 6.8 µF 35V tantalum smd 510-2635-689
C 162 .0047 µF ±10% smd 510-3606-472
C 163 150 pF ±5% NPO 50V cer smd 510-3601-151
C 165 150 pF ±5% NPO 50V cer smd 510-3601-151
C 166 6.8 µF 35V tantalum smd 510-2635-689
C 167 6.8 µF 35V tantalum smd 510-2635-689
C 201 .018 µF ±10% X7R 50V cer smd 510-3605-183
C 202 150 pF, ±1%, high Q, 0805 510-3661-151
C 203 1500 µF 25V alum electrolytic 510-4055-152
C 204 .018 µF ±10% X7R 50V cer smd 510-3605-183
C 205 150 pF, ±1%, high Q, 0805 510-3601-151
C 208 .1 µF ±10% X7R 50V cer smd 510-3606-104
C 209 10 µF 25V tantalum smd 510-2627-100
C 210 1 µF ±10% X7R 16V cer smd 510-3606-105
C 211 .01 µF X7R ±5% 50V cer smd 510-3609-103
C 212 470 µF 16V electrolytic 510-4056-471
C 214 1 µF ±10% X7R 16V cer smd 510-3606-105
C 215 470 µF 16V electrolytic 510-4056-471
C 216 1 µF ±10% X7R 16V cer smd 510-3606-105
C 217 6.8 pF, ±1%, high Q, 0805 510-3661-689
C 218 24 pF, ±1%, high Q, 0805 510-3661-240
C 220 33 pF, ±1%, high Q, 0805 510-3661-330
C 221 39 pF, ±1%, high Q, 0805 510-3661-390
C 223 24 pF, ±1%, high Q, 0805 510-3661-240
C 224 18 pF, ±1%, high Q, 0805 510-3661-180
C 227 47 pF, ±1%, high Q, 0805 510-3661-470
C 228 8.2 pF, ±.1 pF, high Q, smd 510-3667-829
C 230 6.8 pF, ±1%, high Q, 0805 510-3661-689
C 300 150 pF, ±1%, high Q, smd 510-3666-151
Ref No. Description Part No.
C 301 3.9 pF, ±1%, high Q, smd 510-3666-399
C 302 5.1 pF, ±1%, high Q, smd 510-3666-519
C 303 5.6 pF, ±1%, high Q, smd 510-3666-569
C 304 5.1 pF, ±1%, high Q, smd 510-3666-519
C 305 3.9 pF, ±1%, high Q, smd 510-3666-399
C 306 1.0 pF, ±.1 pF, high Q, smd 510-3667-109
C 307 240 pF, ±5%, high Q, smd 510-3667-241
C 308 240 pF, ±5%, high Q, smd 510-3667-241
C 401 150 pF ±5% NPO 50V cer smd 510-3601-151
C 402 4.7 pF, ±.1 pF, high Q, smd 510-3607-479
C 403 5.6 pF, ±.1 pF, high Q, smd 510-3607-569
C 404 33 pF ±5% NPO cer smd 510-3601-330
C 405 150 pF ±5% NPO 50V cer smd 510-3601-151
C 406 150 pF ±5% NPO 50V cer smd 510-3601-151
C 407 100 pF, ±5%, high Q, smd 510-3667-101
C 408 150 pF ±5% NPO 50V cer smd 510-3601-151
C 409 6.8 pF ±5% NPO 50V cer smd 510-3601-689
C 410 6.8 pF ±5% NPO 50V cer smd 510-3601-689
C 411 1 µF ±10% X7R 16V cer smd 510-3606-105
C 413 150 pF ±5% NPO 50V cer smd 510-3601-151
C 414 1 µF ±10% X7R 16V cer smd 510-3606-105
C 415 150 pF ±5% NPO 50V cer smd 510-3601-151
C 416 150 pF ±5% NPO 50V cer smd 510-3601-151
C 417 10 pF, ±1%, high Q, cer smd 510-3661-100
C 501 150 pF ±5% NPO 50V cer smd 510-3601-151
C 502 150 pF ±5% NPO 50V cer smd 510-3601-151
C 503 150 pF ±5% NPO 50V cer smd 510-3601-151
C 504 150 pF ±5% NPO 50V cer smd 510-3601-151
C 505 150 pF ±5% NPO 50V cer smd 510-3601-151
C 506 150 pF ±5% NPO 50V cer smd 510-3601-151
C 507 150 pF ±5% NPO 50V cer smd 510-3601-151
C 508 150 pF ±5% NPO 50V cer smd 510-3601-151
C 509 150 pF ±5% NPO 50V cer smd 510-3601-151
C 510 150 pF ±5% NPO 50V cer smd 510-3601-151
C 511 150 pF ±5% NPO 50V cer smd 510-3601-151
C 512 .018 µF ±10% X7R 50V cer smd 510-3605-183
C 513 .01 µF X7R ±10% 50V cer smd 510-3605-103
C 514 150 pF ±5% NPO 50V cer smd 510-3601-151
C 516 .01 µF X7R ±10% 50V cer smd 510-3605-103
C 517 .01 µF X7R ±10% 50V cer smd 510-3605-103
C 518 150 pF ±5% NPO 50V cer smd 510-3601-151
C 519 150 pF ±5% NPO 50V cer smd 510-3601-151
C 521 .01 µF X7R ±10% 50V cer smd 510-3605-103
C 522 .1 µF ±10% X7R 50V cer smd 510-3606-104
C 523 150 pF ±5% NPO 50V cer smd 510-3601-151
Ref No. Description Part No.
UHF 40W PA Board Assembly
