PARTS LIST
7-14
NOTE: Refer to Section 1.12 for version information.
C 524 .1 µF ±10% X7R 50V cer smd 510-3606-104
CR 101 Diode, Hipax Pin, F-1072t 523-1504-036
CR 102 Diode, Hipax Pin, F-1072t 523-1504-036
CR 103 Diode, Hipax Pin, F-1072t 523-1504-036
CR 104 Diode, Hipax Pin, F-1072t 523-1504-036
CR 105 HC diode 523-1504-016
CR 106 Diode, Hipax Pin, F-1072t 523-1504-036
CR 200 Zener overvoltage transient supp. 523-2907-016
CR 401 Pin switching diode 523-1504-001
CR 402 Diode, Hipax Pin, F-1072t 523-1504-036
CR 403 Pin switching diode 523-1504-001
CR 404 Diode, 1 amp, smd, fast recovery 523-1600-001
CR 501 Switching diode 523-1504-002
CR 502 Switching diode 523-1504-002
CR 503 Switching diode 523-1504-002
D 002 Diode, 5 amp, smd, fast recovery 523-1601-550
J 101 Connector, SMT receptacle 515-7111-470
J 102 Connector, 20-pin 515-7111-230
J 401 Connector, SMT receptacle 515-7111-470
L 001 220 nH inductor smd 542-9003-228
L 002 220 nH inductor smd 542-9003-228
L 003 220 nH inductor smd 542-9003-228
L 102 120 nH inductor smd 542-9003-128
L 103 120 nH inductor smd 542-9003-128
L 104 150 nH inductor smd 542-9003-158
L 109 8T .120 in ID smd inductor 542-0020-058
L 110 Ferrite bead smd 517-2503-010
L 111 Ferrite bead smd 517-2503-010
L 115 8T .120 in ID smd inductor 542-0020-058
L 116 Ferrite bead smd 517-2503-010
L 117 Ferrite bead smd 517-2503-010
L 120 10T inductor 016-0020-050
L 121 Ferrite bead smd 517-2503-010
L 122 Ferrite bead smd 517-2503-010
L 123 3T .080 in ID smd inductor 542-0020-033
L 124 3T .080 in ID smd inductor 542-0020-033
L 125 4T .080 in ID smd inductor 542-0020-034
L 126 3T .060 in ID smd inductor 542-0020-013
L 127 3T .060 in ID smd inductor 542-0020-013
L 200 DC line filter 542-5010-003
L 401 3T .100 in ID smd inductor 542-0020-043
Ref No. Description Part No.
L 402 3T .100 in ID smd inductor 542-0020-043
L 403 150 nH inductor smd 542-9003-158
L 404 220 nH inductor smd 542-9003-228
L 501 220 nH inductor smd 542-9003-228
L 503 .018 µH inductor smd 542-9001-187
MP 001 Low-pass filter wrap-around 017-9700-010
PC 001 PC board, UHF 40W PA rev 2
035-5365-5002
Q 001 LDMOS FET, 35W 12.5V 576-0006-453
Q 005 Silicon NPN gen purpose 576-0003-658
Q 010 Dual-Device FET 70W 12.5V 576-0006-454
Q 200 PNP power Darlington amp 576-0007-013
Q 201 PNP switching 576-0003-612
Q 401 Silicon NPN gen purpose 576-0003-658
Q 403 Silicon NPN gen purpose 576-0003-658
Q 501 Silicon NPN gen purpose 576-0003-658
Q 502 PNP switching 576-0003-612
Q 503 Silicon NPN gen purpose 576-0003-658
Q 504 PNP switching 576-0003-612
R 004 100 ohm ±5% 1/8W smd 569-0105-101
R 005 470 ohm ±5% 1W smd 569-0175-471
R 006 22 ohm ±5% 1W smd 569-0175-220
R 007 22 ohm ±5% 1W smd 569-0175-220
R 008 470 ohm ±5% 1W smd 569-0175-471
R 009 10 ohm ±5% 1W smd 569-0175-100
R 107 1.2k ohm ±5% 1/8W smd 569-0105-122
R 109 100 ohm ±5% 1/8W smd 569-0105-101
R 110 100 ohm ±5% 1/8W smd 569-0105-101
R 111 100 ohm ±5% 1/8W smd 569-0105-101
R 112 100 ohm ±5% 1/8W smd 569-0105-101
R 113 100 ohm ±5% 1/8W smd 569-0105-101
R 114 1.0k ohm ±5% 1/8W smd 569-0105-102
R 115 180 ohm ±5% 1/8W smd 569-0105-181
R 117 620 ohm ±5% 1/8W smd 569-0105-621
R 118 390 ohm ±5% 1/8W smd 569-0105-391
R 119 620 ohm ±5% 1/8W smd 569-0105-621
R 120 470 ohm ±5% 1/8W smd 569-0105-471
R 122 620 ohm ±5% 1/8W smd 569-0105-621
R 123 390 ohm ±5% 1/8W smd 569-0105-391
R 124 1.2k ohm ±5% 1/8W smd 569-0105-122
R 125 100 ohm ±5% 1/8W smd 569-0115-101
R 126 100 ohm ±5% 1/8W smd 569-0105-101
R 127 220k ohm ±5% 1/8W smd 569-0105-224
Ref No. Description Part No.
UHF 40W PA Board Assembly
