R50
1. Check the Connection wire between consoles to MCB. Try to unplug and then plug in the connector
(Page 14, CN2);
2. Check the connection wire between MCB and Induction Brake/Magnet Try to unplug and then plug in the
connector (Page 14, CN4);
3. Check the connection wire between quick key pad and console. Be sure not use wrong connection wire
Quick key on handlebar right/left (Fig1) /Handlebar connection to console. (Fig2)
Fig1
. Fig2
3.4.8. TROUBLESHOOTING – HEART RATE ISSUES
Symptom:
The console does not display heart rate or it is consistently inaccurate.
Possible Reason:
a. The heart rate grips are not connected correctly.
b. The heart rate wiring is damaged.
c. The heart rate board or console is defective.
To Next Page
