2.3CONSOLE DESCRIPTION-XR-CONTINUED
D) ENTER: Confirm each program setting. Press to change display feedback during workout. Press and hold to
scan.
E) ARROWS: Used to adjust program settings.
F) NUMBER KEYPAD: Used to enter XID login or program data during program setup. Also used to adjust
speed/resistance level during workout. Press to confirm setting.
G) BACK: Go to previous program setting.
H) WI-FI CONNECT & SYNC: Press to connect to wireless Internet. See BEFORE YOU BEGIN section for
more info.
I) PASSPORT CONNECT & SYNC: Press to connect your Passport box for Virtual Active programming.
Passport Player is sold at your retailer or at www.passportplayer.com
J) ENERGY SAVER LIGHT: Indicates if machine is in energy saver mode. Press any key to wake up the
machine.
K) READING RACK: Holds reading material or electronic device.
XR DISPLAY DESCRIPTION
A) TIME: Is always shown in the larger, central portion of the display. Shown as minutes: seconds. View
the time remaining or the time elapsed in your workout.
B) INCLINE: Shown as percent. Indicates the incline of your walking or running surface (Treadmills and
Ascents only).
C) DISTANCE: Shown as Miles or Kilometers* based on your default setting. Indicates distance traveled or
distance remaining during your workout.
D) SPEED: Shown as MPH or KPH* based on your default setting. Indicates how fast the footpads/pedals are
moving.
E) CALORIES: Total calories burned or calories remaining to burn during your workout.
F) HEART RATE: Shown as BPM (beats per minute). Used to monitor your heart rate (when wearing a
wireless heart rate strap or when contact is made with both pulse grips).
G) RESISTANCE (RES): Shows the current resistance level (Bikes, Ellipticals, Ascents only).
H) RPM: Revolutions Per Minute (Bikes, Ellipticals, Ascents only).
I) WATTS: Displays current user power output (Bikes, Ellipticals, Ascents only).
J) PACE: Indicates how many minutes it takes to complete a mile based on your current speed (Treadmills
only).
K) PROGRAM PROFILE: The dot matrix will show the program profile as you progress through your workout.
Profile represents incline, resistance or speed (depending on model type and workout type).
L) PASSPORT: Indicates Passport box connection is present.
M) WI-FI: Indicates wireless connection is present and the strength (low, medium, high). Flashes when Wi-Fi
is trying to connect.
* Default is set during console install. If logged in with XID, the default is set by user profile.
