26 - 40
cube
11
13
14
12
Fig. 11: Remove the lid by pulling it
upwards.
Fig. 12: Gently unscrew the ionising tubes
by acting on the glass surface that can be
reached by hand through the special slots.
Fig. 13: Pull off the outer mesh from the
tube. If this is difficult to do, turn the mesh
around the glass while pulling to remove it.
Check that the ionizing tube is in
good conditions: there must not
be any cracks or other damage;
otherwise it must be replaced.
Fig. 14: Clean the glass using a damp
cloth.
Do not use liquid cleaners,
sprays, soap or other
products.
