Jonsered FR2218FA - Seat; Fuelling; Release Lever

English – 13
PRESENTATION
Combi-unit 40-90 mm (1 9/16” - 3 9/16”)
Seat
The seat has a jointed attachment on the front edge and can
be tipped forward.
The seat can also be adjusted lengthways.
Loosen the handles under the seat and adjust it forwards or
bac
kwards to the desired position.
Fuelling
The engine runs on unleaded petrol with a minimum octane
rating of 85 (not mixed with oil). We recommend the use of
biodegradable alkylate petrol. Do not use petrol that contains
methanol.
Do not fill the tank completely, leave an expansion area of at
least 2.5 cm (1“).
Release lever
The release control must be pulled out in order for the
machine to be moved when the engine is shutoff.
Should you attempt to drive the machine with the clutch
controls pulled out it will not mo
ve. The drive on the axle is
disengaged when one of the controls is pulled out.
Pull the controls to the end positions, do not use an
inter
mediate position.
Release lever FR 2218FA 4X4
FR 2218 FA 4X4 has one control for the front axle and one
control for the rear axle.
• Clutch control, rear axle
- Control drawn out, drive system disengaged.
- Control depressed, drive system engaged.
• Clutch control, front axle
The control is positioned on the inside of the left front wheel.
- Rear control (pulled out), drive system disengaged.
- Front control (pushed in), drive system engaged.
Release lever FR 2216 FA
• Pull out the control to disengage the drive system.
• Push in the control to engage to the drive system.
!
WARNING! Petrol is highly inflammable.
Exercise care and refuel outdoors (see
safety instructions).
IMPORTANT!
Do not use the fuel tank as a support area.
IMPORTANT! Always drive the machine with both clutch
controls pressed in.
