20 FrequencyModulation(TTL)
22 A. ControlthepulsewidthENABLE
B. HighLevel:RedBeamTurnedOn;
LowLevel:RedBeamTurnedOff .
18 MOsignalforturnon/of
f
highlevelisjustasopenandlowlevelisjustasoff.
The laser will shooting after turning on the laser for 12s
togetherwiththerisingofMO
9,17,23,24,25
Noneedtoconnect
3.1.1 Interface Setting
Please set the current of pump laser diode which is the output power through a combination of
TTL signals of PIN1~8. The encoding can be set within the range of 0~255 which is
corresponding to the 0~100% power output power (the actual optical power output may not be a
linear relationship with these settings). Please refer to the description in table 7:
Table 7 Current setting of the MOPA fiber laser
 Setting1 Setting2 Setting3 Setting4
PIN1 0 0 0 0
PIN2 0 0 0 0
PIN3 0 0 0 0
PIN4 0 0 0 0
PIN5 0 0 0 1
PIN6 0 0 1 1
PIN7 0 1 1 1
PIN8 1 1 1 1
Current ~50% ~75% ~87.5% ~93.75%
