JR XP652 User Manual

On some types of aircraft, it is desirable to mix
aileron and rudder to make coordinated turns. The
XP652 allows the mixing of ailerons to rudder and
allows you to adjust the amount and direction of
mixing. The aileron to rudder mixing can be left on all
the time, or it can be turned off with the selection of
one of three switches.
1. Turn on the transmitter.
2. Press the MODE and CHANNEL buttons
simultaneously to enter the function mode.
3. Press the MODE button until MIX A-R appears on
the screen.
4. Press the INCREASE or DECREASE button to set
the desired amount and direction of aileron to
rudder mixing.
Note: If OF appears on the screen it is because the
aileron to rudder mixing switch is in the off
position.
Accessing the Aileron to Rudder Mixing Function
AILERON TO RUDDER MIXING
•
Function Mode
7.6
MIX
A-R
+0
%
MIXING VALUE (0-125%)
INDICATES THE AILERON TO
RUDDER MIXING FUNCTION
MIXING DIRECTION
–
+
MODE
ENTER
CHANNEL INCREASE
CLEAR
DECREASE
Press the INCREASE or DECREASE button
to set the aileron to rudder mixing value.
Press the INCREASE and DECREASE
buttons simultaneously to set the
aileron to rudder mixing direction.
Press the MODE button
until MIX A-R appears on the
screen.
39
XP652 MANUAL Airplane
